5
CONTROLS AND FUNCTIONS
1
2
3
4
5
6
7
8
9
Record/Shutter/OK/[ ]
When the unit is on Recording, press it for stop
Recording.
When it is at Camera Mode, press it for photo
shooting.
When it is at Playback Mode, press it for
playback pause and play.
When it is at Menu Setting, press it for
activating the selected OSD menu item.
Power/ [ ]
Turn on/off the unit.
AV Output Port
USB Port
LED Lamp
Speaker
Light Indicator
● Steady blue - Unit is powered off and is
charging.
● Steady pink - Unit is Standby Mode,Camera
Mode or Playback Mode.
● Steady red - Unit is at Standby Mode but
not charging.
● Flashing red - Unit is on Recording but not
charging.
● Flashing between blue and pink - Unit is on
Recording and charging.
Arrow Keys/[ ] , [ ]
When the On-Screen Display (OSD) menu is
activated, it is used as directional arrows to
select the desired menu items.
SOS Emergency File Lock/[ ]
When the unit is on recording, press it for file
lock.
Microphone
Menu/[ ]
Turns on the On-Screen Display (OSD) menu,
Exits and saves menu setting. It is not activated
when the unit is on recording.
Please press [ ] to stop recording and back
to Standby Mode.
Mute/[ ]
Press [ ] until icon appears during
recording, the record audio turns off.
Mode/[ ]
It is not activated when the unit is on recording.
Please press [ ] to stop recording and back
to Standby Mode.
Toggle the unit among “Camera Mode”
“Playback Mode” and “Standby Mode”.
2.7” TFT Display Screen
HDMI Output Slot
Reset Key
Reset to Manufacture Settings.
Micro SD Slot
Required a micro SDHC card, class 6 or above
Support 8~32GB.
11
12
13
14
10
15
16
17
