INTRODUCTION OF OTHER FUNCTIONS
13
Loop Recording (default)
Loop Recording can be set at 2/3/5 minutes, it means that the video clip intervals
will be set at 2/3/5 minutes long and after memory card is full, the oldest video
clips will be deleted and new video clips will take its place.
If Loop Recording is turned off, it will stop recording when the memory card is full.
G-Sensor (default at Middle)
When the internal G-Sensor detects situations like an impact, intense bumps or
hard brakes during Recording Mode, the unit will automatically lock the current
recording to avoid being replaced by loop recording.
Motion Detection
In Motion Detection Mode, the surrounding of where the car is parked will be
recorded taking the least amount of storage space. Recording will automatically
be turned off after 10 seconds if nothing happens during the monitor mode. Once
there is movement, the unit will start recording immediately.
* The Motion Detection Mode requires the camera to be connected to a constant
power supply.
When Motion Detection Mode is activated, Monitor Mode/Emergency Recording
Mode and the G-Sensor function will automatically be turned off.
Plate Stamp
Enter your license plate number or desired input, and it will be displayed on the
video footage.
