![Haier HSU-18LEK13/R2 [3/8] Base operation](/views2/1818975/page3/bg3.png)
SPEED
2
Operation
Operation
Mode
AUTO
Remote
Controller
Note
COOL
DRY
HEAT
FAN
In DR Y mode, when room temperature becomes lower than
temp.setting+2
o
C,unit will run intermittently at LOW speed
regardless of FAN setting.
Under the mode of auto operation, air conditioner will
automatically select Cool or Heat operation according to room
temperature.When FAN is set to AUTO, the air conditioner
automatically adjusts the fan speed
temperature.
according to room
In FAN operation mode, the unit will not operate in COOL or
HEAT mode but only in FAN mode,AUTO is notavailable in FAN
mode.And temp.setting is disabled.
In FAN mode,SLEEP operation is not available.
AUTO COOL DRY FAN HEAT
2.Select operation mode
Press FAN SPEED button. For each press, fan speed
follows:
Press MODE button. For each
press, operation mode
changes as follows:
Remote controller:
Remote controller:
Press button
Every time the button is pressed, temp.setting
increase 1
o
C,if kept depressed, it will increase
rapidly
Every time the button is pressed, temp.setting
decrease 1
o
C,if kept depressed, it will decrease
rapidly
Select a desired temperature.
4.Fan speed selection
3.Select temp.setting
Air conditioner is running under displayed fan speed.
When FAN is set to AUTO, the air conditioner automatically
adjusts the fan speed according to room temperature.
LOW
MED
HI
AUTO
1. Unit start
Press ON/OFF on the remote
controller, unit starts.
TEMP+
TEMP-
TEMP+
TEMP-
/
Base Operation
Remote controller
Emergency Operation:
temperature is below 16
o
C, do not use it in the
Test operation:
Use this switch in the test operation when the room
normal operation.
your finger from the switch: the cooling
Continue to press the test operation
switch for more than 5 seconds . After
you hear the "Pi" sound twice,
release
Test operation switch is the same as emergency switch.
operation starts with the air flow speed "Hi".
Emergency operation and test operation
Use this ope
r
ation only when the remote controller
is defective or lost.
When the emergency operation switch is
pressed,the" Pi "sound is heard once
, which
the start of this operation.
In this operation, the system automatically selects
the
operation modes
,cooling or fan or heat,
according to the room temperature.
.
It is not possible to operate in dry mode.
Room
temperature
Operation
mode
Designated
temperature
Timer
mode
Air flow
ABOVE 23
O
C
BELOW 23
O
C
COOLING
HEAT
23
O
C
26
O
C
NO
NO
AUTOMATIC
AUTOMATIC
(C
ooling only uint）
Room temperature
Operation
mode
Designated
temperature
Timer
mode
Air flow
BELOW 23
O
C
FAN
26
O
C
NO
AUTOMATIC
means
changes as
Pi
Pi Pi
Clock set
Press CLOCK button, "AM" or "PM" flashes.
Press or to set correct time. Each press will
change quickly.
After time setting is confirmed,press SET,
"AM "and "PM" stop flashing,while clock starts working.
increase or decrease 1min. If the
button is kept pressed,time will
1
1
2
3
4
1
2
3
Remove the battery cover;
Load the batteries as
illustrated. 2 R-03 batteries,
resetting key(cylinder);
Be sure that the loading
is in line with th
e" + "/"-";
Load the battery,then put on the cover again.
The distance between the signal transmission head and the
receiver hole should be within 7m without any obstacle as well.
When electronic-started type fluorescent lamp or change-over
so the distance to the indoor unit should be shorter.
wireless telephone is installed in the type fluorescent lamp or
room, the receiver is apt to be disturbed in receivingthe signals,
Note:
Full display or unclear display during operation indicates the
ries have been used up.
Please change batteries.
If the remote controller can't run normally during operation,
reload several minutes later.
batte
remove the batteries and
Remove the batteries in case unit won't be in usage for a long period.
If there are any display
after taking-out, just need to press reset key
Hint:
Loading of the battery
please
