Maintenance
Don't be exposed to cold air for
a long time.
Keep heat source away from
air conditioner.
After unit stops, don't restart it
until 3 min. have elapsed.
7
Avoid opening door and window
unless necessary.
Use curtain or blind
Direct sunlight may reduce cooling
effect, always use window curtain.
Set temp. a little bit higher
before going to bed.
No entrance
Keep away from me
OK! enjoy a
3-min nap
