– 8
Clean high-pressure nozzle: Remove dirt
and debris from the nozzle bore, using a
needle and rinse through with water from the
front.
Check water flow quantity.
Slight leakage from the appliance pump is
normal. If the leakage increases contact the
authorized customer service.
Remove the spray lance from the hand spray
gun and work with the hand spray gun only
or use the spray lance with pressure regula-
tion and turn to "Mix".
Clean the detergent suction hose filter.
Check the detergent suction hose for kinks.
Subject to technical modifications!
We hereby declare that the machine described
below complies with the relevant basic safety
and health requirements of the EU Directives,
both in its basic design and construction as well
as in the version put into circulation by us. This
declaration shall cease to be valid if the machine
is modified without our prior approval.
The undersigned act on behalf and under the
power of attorney of the company management.
Authorised Documentation Representative
S. Reiser
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Winnenden, 2011/03/01
Strong pressure fluctuations
Appliance is leaking
No detergent infeed
Technical specifications
Electrical connection
Voltage 220-240
1~50/60
V
Hz
Power consumption 6 A
Connected load 1,3 kW
Protection class IP X5
Protective class II
Mains fuse (slow-blow) 10 A
Water connection
Max. feed temperature 40 °C
Min. feed volume 7 I/min
Feed pressure 0,2-1,2 MPa
Performance data
Working pressure 8 MPa
Max. permissible pressure 10 MPa
Water flow rate 5,2 I/min
Detergent flow rate 0,3 I/min
Recoil force of trigger gun 10 N
Weight, ready to operate with accessories
without storage for accessories 4,7 kg
with storage for accessories 4,9 kg
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
<2,5
0,3
m/s
2
m/s
2
Sound pressure level L
pA
Uncertainty K
pA
75
3
dB(A)
dB(A)
Sound power level L
WA
+ Uncer-
tainty K
WA
91 dB(A)
CE declaration
Product: High-pressure cleaner
Type: 1.673-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2004/108/EC
2000/14/EC
Applied harmonized standards
EN 55014–1: 2006 + A1: 2009
EN 55014–2: 1997 + A2: 2008
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2006 + A2: 2009
EN 61000–3–3: 2008
EN 62233: 2008
Applied conformity evaluation method
2000/14/EC: Appendix V
Sound power level dB(A)
Measured: 89
Guaranteed: 91
CEO
Head of Approbation
15EN
