Indoor unit
Back up switch
Swing louver
Air blows out from here.
Air flow direction is adjusted.
Air inlet grille
Takes in the indoor air.
Air filter
Removes dust or dirt out of the inlet air.
(In the Air inlet grille)
Air inlet
Outdoor unit
Air outlet
Compressor(inside of unit)
