Haier AB142ACBIA [63/365] Panel application for cassette units
![Haier AB142ACBIA [63/365] Panel application for cassette units](/views2/1821723/page63/bg3f.png)
>a__WcU[S^ <[c >a`V[e[a`Wc
panel
model
function description applicable unit
PB-630IA
with elevating function, for 630*630
panel
R407C&R22 unitary free fixed frequency&inverter
AB09~18, R407C&R22 free multi 07~18
PB-630IB
without elevating function, for 630*630
panel
R407C&R22 unitary freefixed frequency&inverter
AB09~18, R407C&R22 free multi 07~18,R407C H-
MRV 09~18, R407C C-MRV 09~16, R22 H-MRV
09~18
PB-630IC
1.for 600*600 panel,2.without elevating
function,3.Based on PB-630IB,add one
swing motor
R407C&R22 unitary freefixed frequency&inverter
AB09~18, R407C&R22 free multi 07~18,R407C H-
MRV 09~18, R407C C-MRV 09~16, R22 H-MRV
09~18
PB-630ID
1.for 600*600 panel,2.with elevating
function,3.Based on PB-630IA,add one
swing motor
R407C&R22 unitary freefixed frequency&inverter
AB09~18, R407C&R22 free multi 07~18
PB-950IA
for 950*950 panel, universal for wired
control type and infrared control type
R407C&R22 unitary freefixed frequency&inverter
AB24~28, R407C free multi 21~28, R22 free multi
21~42, R407C&R22 C-MRV 18~28
PB-1340IA
for 950*1340 panel, universal for wired
control type and infrared control type
R407C&R22 unitary freefixed frequency AB36~52,
R407C free multi 42, C-MRV 32~45
Panel application for cassette units
-63-
