Philips PicoPix Micro 2 PPX340/INT [5/20] Overview
![Philips PicoPix Micro 2 PPX340/INT [5/20] Overview](/views2/1822493/page5/bg5.png)
Overview 5
Power supply
Use only a power adapter which is certified for
this product (see Technical data, page 17).
Check whether the mains voltage of the power
supply matches the mains voltage available at
the setup location. This product complies with
the voltage type specified on the product.
The power outlet shall be installed near the
product and shall be easily accessible.
The capacity of the built-in battery diminishes
with time. If the product functions only with AC
power supply, the built-in battery is defective.
Contact an authorised service centre to replace
the built-in battery.
CAUTION!
Always use the button to turn the
projector off.
Turn off the product and unplug from the
power outlet before cleaning the surface
(see Cleaning, page 14). Use a soft, lint-
free cloth. Never use liquid, gaseous or easily
flammable cleaners (sprays, abrasives, polishes,
alcohol). Do not allow any moisture to reach
the interior of the product.
DANGER!
Risk of eye irritation!
This product is equipped with a high
power LED (Light Emitting Diode),
which emits very bright light. Do not
look directly into the projector lens
during operation. This could cause eye
irritation or damage.
2 Overview
Rear view
HDMI
DC
USB
cbadefg
hijkl
a
IR sensor
b
Reset key
Reset the projector to the factory default
settings (use a small pin to press the reset
key).
c
DC socket
Connect to the power supply.
d
HDMI port
Connect to the HDMI output on a playback
device.
e
3.5 mm audio output; connect to external
speakers or headphones.
f
USB port
Connect to power USB devices like Amazon
Fire TV stick®, Roku® streaming stick (not
for mass storage or media player).
g
port
Connect to the USB-C video output on a
playback device.
h
• Access the settings menu.
• Confirm a selection or entry.
i
• Navigate menu options�
• Increase volume.
j
• Navigate menu options�
• Decrease volume.
k
Return to a previous menu screen.
