10 to 13 SEER 1.5 to 5 Tons

Models: HC18-60A1VAR/S

HC18-60C1VAR

HC18-60D1VAR

Installation & Operation Manual

Central Air Conditioner

The information contained in this booklet is subject to change without notice.

Содержание

Central air conditioner 1
Installation operation manual 1
Warning 2
Introduction 3
Nomenclature for model number 3
Table of content 3
Model hc18 60a1var s 4
Specification 4
Table 1 4
The dimensions for the condensing unit are illustrated in figure 1 physical and electrical specifications are provided in table 1 for 10 seer systems respectively 4
Figure 1 5
Model hc18 60c1var table 3 5
Table 2 system cooling capacity 5
The dimensions for the condensing unit are illustrated in figure 1 physical and electrical specifications are provided in table 3 for 12 seer systems respectively 5
Model hc18 60d1var 6
Table 4 system cooling capacity 6
Table 5 6
Table 6 system cooling capacity 6
The dimensions for the condensing unit are illustrated in figure 1 physical and electrical specifications are provided in table 5 for 13 seer systems respectively 6
Equipment protection from environment 7
Installation 7
Unit inspection 7
Do not allow the vapor line and liquid line to touch together this would cause an undesirable heat transfer resulting in capacity loss and increased power consumption 9
Figure 3 9
Line insulation suction line requires insulation in order to prevent condensation from forming on the piping and to prevent heat gain caused by surrounding air generally 3 8 wall thickness of armflex or equivalent is satisfactory in severe application hot high humidity areas greater thickness may be required apply the line insulation by sliding it on the sealed tuing before cutting and making connections 9
Liquid line does not necessarily need insulation however if they are exposed to high ambient temperatures i e kitchen boiler rooms hot attics rooftop surface then they should be insulated make sure to use the proper size tubing for the liquid line to prevent liquid refrigerant flashing to a vapor within the liquid line 9
Electrical wiring 12
System startup 13
Miscellaneous 14
Operation 14
Air conditioner wi ring diagram 16
Br brown gr green or orange 16
Color codes bk black bl blue gy gray 16
Component codes bcr blower control relay bcap run capacitor blower motor cc compressor contactor cch crankcase heater optional chs crankcase heater switch optional cmpr compressor hps high pressure switch lps low pressure switch ibm indoor blower motor ofm outdoor fan motor rcap run capacitor compressor rvs reversing valve solenoid stcap start capa citor optional strly start relay optional strth start thermistor optional tran transformer 230 208 selectable 16
Compress or protect 3 min time delay 16
Compressor 16
Ha cool off heat 16
Hc18 60a1var s hc18 60c1var hc18 60d1var 16
Line volta ge factory standard field installed optional low voltage factory standard field installed optional 16
Optional low high pressur e switches 16
Pu purple rd red vi violet 16
Use copper conductors only warning cabinet must be permanently grounded and all wiring to conform to i e c n e c c e c c l c and local codes as applicable replacement wire must be the same gage and insulation type as original wire 16
Vac common 16
Wh white yl yellow 16
