HW120-B14876
●
Delay I-time Temp . Speed Rinse Water leve l Start/Paus e
R
Mix
Wool
Shirts
Duvet
Sanitize
Underwear
Kids Wear
Casual Wears
Rinse+Spin
Spin
Hygienic
Quick 15 Bedding
rpm
1400
Capacity
12kg
ABT
99%
Intense
Self Clean
Delicate
2-Product description
7
2.1 Picture of appliance
Front (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
●
Check the accessories and li
●
terature in accordance with this list (Fig.2-3):
Inlet hose
assembly
6 Blanking
plugs and 2 Bolts
Drain hose
bracket
User manual
Warranty-card
Note:
2-3
21 3 4 5 6
7
1 Detergent / Softener
drawer
2 Worktop
3 Display
4 Programme selector
5 Panel
6
7 Sevice flap
8 Adjustable feet
Door handle
(Picture is schematic, please refer to actual product)
R5
R6
Bottom plate
R7
R8
R9
R10
1
Iron bar (I1-I2)
2 Transportation bolts (T1 -T4)
3 Rearward reinforcement
4 Power cord
5 Water inlet valve
6 Drain hose
7 Rearward reinforcement
(The 8kg model has only one rearward
reinforcement below)
