Haier HW90-B14636 [26/100] Installation

10-Installation

Following connections are possible:

●

10.5.1 Drain hose to sink

edge of a sink with adequate size (Fig. 10-6).

●

ping.

10.5.2 Drain hose to waste water connection

●

The internal diameter of the stand pipe with

vent-hole must be minimum 40 mm.

Put the drain hose for approx. 80 mm in the

wastewater pipe.

(Fig. 10-7).

10-6 10-7

10.5 Drain Water Connection

Fix the water drain hose properly to the piping. The hose has to reach at one point a height

WARNING!

Only connect to cold water supply.

Before connection, check whether the water is clean and clear.

10.4 Aligning the appliance

Adjust all feet (Fig. 10-5) to achieve a complete level

position. This will minimize vibrations and thus noise

during use. It will also reduce wear and tear. We recom-

mend to use a spirit level for adjustment. Floor should

1. Loose the locknut (1) by using a wrench.

2. Adjust the high by turning the foot (2).

3. Tighten locknut (1) against the housing.

10-5
