2.1 Picture of appliance
Front side (Fig. 2-1): Rear side (Fig. 2-2):
2.2 Accessories
Check the accessories and literature in accordance with this list (Fig.2-3):
Note :
1 Detergent/Softener drawer
2
Control panel
3
Worktop
4 Door
5 Filter cover
6 Adjustable feet
1 Transit bolts (T1-T4)
2 Backcover
Backcover screws（7 EA）
3
4 Power cord
5 Water inlet valve
6 Drain hose
2-1 2-2
2-3
ript
Inlet hose
assembly
5 Blanking
plugs+2 Screws
Drain hose
bracket
User manual
Bottom plate
Due to technical changes and different models,the illustrations in the following
pictures may differ from your model.
1 32
6
4
5
1
2
3 4 5 6
T1
T2
