Haier HNS1260TVE [12/27] Net dimension
![Haier HNS1260TVE [12/27] Net dimension](/views2/1828192/page12/bgc.png)
Page 11
height: 850mm / width: 595mm / depth: 565mm
Net Dimension
595
850
565
Front Load Washing Machine
Model:HNS1260TVE/ME
