Haier HNS1260TVE [24/27] Failure water leaking troubleshooting
![Haier HNS1260TVE [24/27] Failure water leaking troubleshooting](/views2/1828192/page24/bg18.png)
Page 23
Failure:water leaking
Troubleshooting:
N
N
Check if water is leaking from the inlet pipe
or the tap
N
N
N
Check if all tubes and tie-in is leaking
water, including the connecting of tube
and valve, dispenser, tube and
dispenser ,outer cylinder-cushion of sight
window-hose and outer cylinder, drain
pump and gas valve
Check if there is foreign material nipped
between cushion of sight window and
sight window
Is water leaking from outer cylinder?
Is cushion of sight window broken?
Is drain pipe broken
Readjust it.
Y
Y
Y
Y
Replace drain pipe
Remove clothes
Reassemble or repair
Replace cushion of sight
window
Y
Replace outer cylinder
Y
Front Load Washing Machine
Model:HNS1260TVE/ME
