7
ENGLISH
Removing and refi tting the chuck (fi g. E)
♦ Open the chuck as far as possible.
♦ Remove the chuck retaining screw, located
in the chuck, by turning it clockwise using
a screwdriver.
♦ Tighten an Allen key into the chuck and strike
it with a hammer as shown.
♦ Remove the Allen key.
♦ Remove the chuck by turning it
counterclockwise.
♦ To refi t the chuck, screw it onto the spindle
and secure it with the chuck retaining screw.
Use
Warning! Let the tool work at its own pace. Do
not overload.
Warning! Before drilling into walls, fl oors or
ceilings, check for the location of wiring and pipes.
Selecting the drilling mode
♦ For hammer drilling in masonry and concrete,
set the operating mode selector (6) to the
position.
♦ For drilling in steel, wood and plastics, set the
operating mode selector (6) to the position.
Two-gear selector (fi g. A)
♦ For drilling in steel and for screwdriving
applications, turn the two-gear selector (5)
into position 1 by aligning the arrow (10) with
the number 1 (1st gear).
♦ For drilling in materials other than steel, turn
the two-gear selector (5) into position 2 by
aligning the arrow (10) with the number 2 (2nd
gear).
Selecting the direction of rotation
For drilling and tightening screws, use forward
(clockwise) rotation. For loosening screws
or removing a jammed drill bit, use reverse
(counterclockwise) rotation.
♦ To select forward rotation, push the forward/
reverse slider (4) to the left.
♦ To select reverse rotation, push the forward/
reverse slider to the right.
Warning! Never change the direction of rotation
while the motor is running.
Switching on and off
♦ To switch the tool on, press the variable speed
switch (1). The tool speed depends on how far
you press the switch. If the tool has a variable
speed control knob (3), set it to the required
speed range. As a general rule, use low
speeds for large diameter drill bits and high
speeds for smaller diameter drill bits.
♦ For continuous operation, press the lock-on
button (2) and release the variable speed
switch. This option is available only at full
speed or at any speed preset with the variable
speed control knob (3). This option does not
work in reverse rotation.
♦ To switch the tool off, release the variable
speed switch. To switch the tool off when
in continuous operation, press the variable
speed switch once more and release it.
Accessories
The performance of your tool depends on
the accessory used. Black & Decker and
Piranha accessories are engineered to high
quality standards and designed to enhance
the performance of your tool. By using these
accessories you will get the very best from your
tool.
Maintenance
Your Black & Decker corded/cordless appliance/
tool has been designed to operate over a long
period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon
proper tool care and regular cleaning.
Warning! Before performing any maintenance on
corded/cordless power tools:
♦ Switch off and unplug the appliance/tool.
♦ Or switch off and remove the battery from
the appliance/tool if the appliance/tool has
a separate battery pack.
♦ Or run the battery down completely if it is
integral and then switch off.
♦ Unplug the charger before cleaning it. Your
charger does not require any maintenance
apart from regular cleaning.
♦ Regularly clean the ventilation slots in your
appliance/tool/charger using a soft brush or
dry cloth.
♦ Regularly clean the motor housing using
a damp cloth. Do not use any abrasive or
solvent-based cleaner.
♦ Regularly open the chuck and tap it to remove
any dust from the interior (when fi tted).
Mains plug replacement
(U.K. & Ireland only)
If a new mains plug needs to be fi tted:
♦ Safely dispose of the old plug.
♦ Connect the brown lead to the live terminal in
the new plug.
