8
Switching on and off
u To switch the tool on, press the variable speed switch (1).
The tool speed depends on how far you press the switch.
u As a general rule, use low speeds for large diameter drill
bits and high speeds for smaller diameter drill bits.
u For continuous operation, press the lock-on button (2) and
release the variable speed switch. This option is available
only in forward (clockwise) rotation.
u To switch the tool off, release the variable speed switch.
To switch the tool off when in continuous operation, press
the variable speed switch once more and release it.
Accessories
The performance of your tool depends on the accessory used.
Black & Decker and Piranha accessories are engineered to
high quality standards and designed to enhance the performance
of your tool. By using these accessories you will get the very
best from your tool.
Maintenance
Your tool has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper tool care and regular cleaning.
Warning! Before performing any maintenance, switch off and
unplug the tool.
u Switch off and unplug the appliance/tool.
u Or switch off and remove the battery from the appliance/
tool if the appliance/tool has a separate battery pack.
u Or run the battery down completely if it is integral and then
switch off.
u Unplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
u Regularly clean the ventilation slots in your tool using a
soft brush or dry cloth.
u Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
u Regularly open the chuck and tap it to remove any dust
from the interior (when tted).
Mains plug replacement (U.K. & Ireland only)
If a new mains plug needs to be tted:
u Safely dispose of the old plug.
u Connect the brown lead to the live terminal in the new plug.
u Connect the blue lead to the neutral terminal.
Warning! No connection is to be made to the earth terminal.
Follow the tting instructions supplied with good quality plugs.
Recommended fuse: 5 A.
Protecting the environment
Z
Separate collection. This product must not be
disposed of with normal household waste.
Should you nd one day that your Black & Decker product
needs replacement, or if it is of no further use to you, do not
dispose of it with household waste. Make this product
available for separate collection.
z
Separate collection of used products and packaging
allows materials to be recycled and used again.
Re-use of recycled materials helps prevent
environmental pollution and reduces the demand for
raw materials.
Local regulations may provide for separate collection of
electrical products from the household, at municipal waste
sites or by the retailer when you purchase a new product.
Black & Decker provides a facility for the collection and
recycling of Black & Decker products once they have reached
the end of their working life. To take advantage of this service
please return your product to any authorised repair agent who
will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker ofce at the
address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com
Technical data
KD855 KD860 KD885
TYPE 1/2 TYPE 1/2 TYPE 1/2
Input voltage V
AC
230 230 230
Power input W 550 600 550
No-load speed min
-1
0 - 960 0 - 960 0 - 960
Impact rate min
-1
0 - 5,100 0 - 5,100 0 - 5,100
Impact energy J 1.6 1.6 1.6
Max. drilling capacity
Concrete mm 20 20 20
Steel mm 13 13 13
Wood mm 30 30 30
Weight kg 2.8 2.8 2.8
Level of sound pressure according to EN 60745:
Sound pressure (L
pA
) 89.5 dB(A), uncertainty (K) 3 dB(A)
Sound power (L
WA
) 100.5 dB(A), uncertainty (K) 3 dB(A)
