17
KFKD middle static pressure duct
Cooling Capacities (with fan at high speed)
KFKD89H0EN1
KFKD89H0EN1
Air inlet condition
EWT ∆t
DB:21 WB:15 DB:26.7 WB:19.4 DB:27 WB:19 DB:29 WB:21 DB:33 WB:25
TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD TC SC WF WPD
3
7.36 5.34 2.11 41.8 11.34 6.83 3.25 99.2 11.11 7.13 3.18 95.2 12.41 6.51 3.56 118.7 16.70 8.09 4.79 215.1
4
6.92 5.05 1.49 20.8 10.90 6.63 2.34 51.6 10.72 6.92 2.31 49.9 11.92 6.29 2.56 61.6 16.18 7.83 3.48 113.6
5 5
6.40 4.83 1.10 11.4 10.43 6.40 1.79 30.2 10.22 6.70 1.76 29.0 11.46 9.90 1.97 36.4 15.67 7.71 2.69 68.2
6
5.84 4.62 0.84 6.6 9.97 6.22 1.43 19.2 9.77 6.47 1.40 18.4 10.95 5.83 1.57 23.1 15.28 7.45 2.19 45.0
7
5.24 4.33 0.64 3.9 9.48 5.92 1.16 12.7 9.26 6.25 1.14 12.1 10.49 5.60 1.29 15.6 14.77 7.19 1.81 30.9
3
6.65 5.03 1.91 34.1 10.70 6.56 3.07 88.3 10.45 6.85 3.00 84.3 11.78 6.22 3.38 107.0 16.05 7.83 4.60 198.8
4
6.18 4.79 1.33 16.6 10.27 6.33 2.21 45.8 10.03 6.61 2.16 43.7 11.30 6.01 2.43 55.4 15.54 7.58 3.34 104.8
6 5
5.70 4.57 0.98 9.0 9.77 6.10 1.68 26.5 9.58 6.42 1.65 25.5 10.85 5.78 1.87 32.7 15.03 7.32 2.58 62.7
6
5.12 4.37 0.73 5.1 9.31 5.92 1.33 16.7 9.09 6.18 1.30 15.9 10.31 5.52 1.48 20.5 14.64 7.06 2.10 41.3
7
4.51 4.06 0.55 2.9 8.82 5.65 1.08 11.0 8.60 6.01 1.06 10.5 9.85 5.29 1.21 13.7 14.13 6.94 1.74 28.3
3
5.95 4.73 1.70 27.3 9.99 6.24 2.86 77.0 9.77 6.56 2.80 73.7 11.08 5.91 3.18 94.8 15.28 7.45 4.38 180.2
4
5.46 4.55 1.17 12.9 9.58 6.02 2.06 39.8 9.32 6.34 2.00 37.7 10.65 5.72 2.29 49.2 14.90 7.32 3.20 96.3
7 5
4.93 4.33 0.85 6.8 9.09 5.80 1.56 23.0 8.9 6.13 1.53 22 10.13 5.48 1.74 28.5 14.38 7.06 2.47 57.5
6
4.34 4.11 0.62 3.6 8.62 5.64 1.24 14.3 8.46 5.91 1.21 13.8 9.67 5.24 1.39 18.0 14.00 6.81 2.01 37.8
7
3.76 3.76 0.46 2.0 8.16 5.38 1.00 9.4 7.89 5.73 0.97 8.8 9.16 5.02 1.12 11.9 13.48 6.55 1.66 25.8
3
5.21 4.48 1.49 21.0 9.31 5.97 2.67 66.9 9.09 6.25 2.61 63.8 10.42 5.59 2.99 83.7 14.64 7.19 4.20 165.4
4
4.70 4.34 1.01 9.6 8.90 5.77 1.91 34.4 8.63 6.11 1.86 32.3 9.91 5.42 2.13 42.7 14.13 6.94 3.04 86.6
8 5
4.16 4.07 0.72 4.8 8.45 5.52 1.45 19.8 8.19 5.86 1.41 18.6 9.49 5.20 1.63 25.0 13.74 6.68 2.36 52.4
6
3.74 3.74 0.54 2.7 7.90 5.36 1.13 12.0 7.74 5.65 1.11 11.6 9.02 4.96 1.29 15.7 13.23 6.55 1.90 33.7
7
3.26 3.26 0.40 1.5 7.44 5.11 0.91 7.8 7.20 5.46 0.89 7.4 8.44 4.75 1.04 10.1 12.77 6.31 1.57 23.1
3
4.46 4.23 1.28 15.3 8.66 5.70 2.48 57.8 8.41 5.98 2.41 54.6 9.72 5.32 2.79 72.9 14.00 6.94 4.01 151.2
4
4.05 4.05 0.87 7.1 8.17 5.50 1.76 29.0 7.92 5.80 1.70 27.2 9.22 5.12 1.98 36.9 13.48 6.68 2.90 78.9
9 5
3.74 3.62 0.64 3.9 7.73 5.27 1.33 16.6 7.49 5.61 1.29 15.6 8.77 4.89 1.51 21.4 13.10 6.42 2.25 47.7
6
3.27 3.27 0.47 2.1 7.22 5.07 1.03 10.0 6.96 5.43 1.00 9.3 8.31 4.66 1.19 13.3 12.55 6.28 1.80 30.4
7
2.67 2.67 0.33 1.0 6.68 4.83 0.82 6.3 6.45 5.19 0.79 5.9 7.73 4.46 0.95 8.5 12.12 6.05 1.49 20.8
3
3.93 3.93 1.13 11.9 7.94 5.41 2.28 48.6 7.62 5.77 2.18 44.7 9.04 5.03 2.59 63.1 13.36 6.55 3.83 137.6
4
3.61 3.61 0.78 5.7 7.45 5.20 1.60 24.1 7.19 5.57 1.55 22.4 8.51 4.84 1.83 31.5 12.80 6.42 2.75 71.1
10 5
3.22 3.22 0.55 2.9 6.96 5.03 1.20 13.5 6.67 5.39 1.15 12.3 8.07 4.62 1.39 18.1 12.41 6.19 2.13 42.7
6
2.76 2.76 0.40 1.5 6.49 4.82 0.93 8.1 6.19 5.19 0.89 7.4 7.54 4.39 1.08 11.0 11.87 6.02 1.70 27.2
7
1.76 1.76 0.22 0.4 5.92 4.61 0.73 5.0 5.64 5.00 0.69 4.5 7.05 4.17 0.87 7.0 11.34 5.78 1.39 18.2
3
3.47 3.47 0.99 9.3 7.17 5.16 2.05 39.6 6.91 5.50 1.98 36.8 8.31 4.76 2.38 53.3 12.60 6.31 3.61 122.5
4
3.17 3.17 0.68 4.4 6.72 4.98 1.44 19.6 6.45 5.29 1.39 18.0 7.85 4.57 1.69 26.7 12.08 6.14 2.60 63.4
11 5
2.75 2.75 0.47 2.1 6.20 4.79 1.07 10.7 5.92 5.16 1.02 9.7 7.33 4.35 1.26 14.9 11.70 5.92 2.01 38.0
6
2.18 2.18 0.31 0.9 5.65 4.60 0.81 6.2 5.43 4.93 0.78 5.7 6.81 4.14 0.98 8.9 11.16 5.77 1.60 24.0
7
1.
48
1.48 0.18 0.3 5.03 4.43 0.62 3.6 4.85 4.85 0.60 3.3 6.27 3.89 0.77 5.6 10.65 5.52 1.31 16.1
3
3.06 3.06 0.88 7.2 6.41 4.92 1.84 31.7 6.10 5.30 1.75 28.7 7.55 4.51 2.16 44.0 11.89 6.06 3.41 109.1
4
2.70 2.70 0.58 3.2 5.93 4.75 1.28 15.3 5.64 5.12 1.21 13.8 7.10 4.30 1.53 21.9 11.39 5.87 2.45 56.3
12 5
2.32 2.32 0.40 1.5 5.42 4.58 0.93 8.2 5.14 4.96 0.88 7.3 6.59 4.11 1.13 12.1 10.95 5.65 1.88 33.3
6
1.40 1.40 0.20 0.4 4.82 4.43 0.69 4.5 4.76 4.67 0.68 4.4 6.04 3.88 0.87 7.0 10.43 5.50 1.49 21.0
7
1.16 1.16 0.14 0.2 4.26 4.26 0.52 2.6 4.39 4.39 0.54 2.7 5.48 3.65 0.67 4.3 9.91 5.28 1.22 13.9
3
2.63 2.63 0.75 5.3 5.60 4.70 1.61 24.2 5.28 5.10 1.51 21.5 6.81 4.25 1.95 35.7 11.13 5.82 3.19 95.7
4
2.25 2.25 0.48 2.2 5.12 4.52 1.10 11.4 4.94 4.85 1.06 10.6 6.32 4.05 1.36 17.3 10.66 5.60 2.29 49.3
13
5
1.62 1.62 0.28 0.7 4.57 4.47 0.79 5.8 4.62 4.62 0.80 5.9 5.82 3.85 1.00 9.4 10.18 5.38 1.75 28.8
6
1.08 1.08 0.15 0.2 4.16 4.16 0.60 3.3 4.30 4.30 0.62 3.6 5.25 3.65 0.75 5.3 9.66 5.24 1.38 18.0
7
0.80 0.80 0.10 0.1 3.80 3.80 0.47 2.0 3.96 3.96 0.49 2.2 4.60 3.44 0.56 3.0 9.16 5.02 1.12 11.9
