Black & Decker KW712 [8/76] Assembling and ﬁ tting the shavings collection bag ﬁ g e

ENGLISH

Assembling and ﬁ tting the shavings

collection bag (ﬁ g. E)

The shavings collection bag is particularly useful

when working in conﬁ ned spaces.

Before ﬁ rst use, you will have to assemble the

shavings collection bag.

♦ Fit the wire frames (14) to the connecting plate

(15) using the screws (16) and washers (17).

♦ Pull the cloth bag (18) over the frame structure

as shown. Take care that the elasticated

mouth (19) is well ﬁ tted around the edge of the

connecting plate (15).

♦ Slide the connecting plate over the shavings

discharge outlet (3).

Residual risks.

Additional residual risks may arise when using the

tool which may not be included in the enclosed

safety warnings. These risks can arise from

misuse, prolonged use etc.

Even with the application of the relevant safety

regulations and the implementation of safety

devices, certain residual risks can not be avoided.

These include:

♦ Injuries caused by touching any rotating/

moving parts.

♦ Injuries caused when changing any parts,

blades or accessories.

♦ Injuries caused by prolonged use of a tool.

When using any tool for prolonged periods

ensure you take regular breaks.

♦ Impairment of hearing.

♦ Health hazards caused by breathing dust

developed when using your tool (example:-

working with wood, especially oak, beech

and MDF.)

Use

Warning! Let the tool work at its own pace. Do not

overload.

♦ Adjust the depth of cut.

♦ If necessary, ﬁ t and adjust the parallel fence.

Switching on and off

Switching on

♦ Keep the lock-off button (2) depressed and

press the on/off switch (1).

♦ Release the lock-off button.

Switching off

♦ Release the on/off switch.

Planing

♦ Hold the tool with the nose piece of the shoe

resting on top of the workpiece surface.

♦ Switch the tool on.

♦ Move the tool steadily forward to perform the

cutting stroke.

♦ Switch the tool off after the stroke has been

completed.

Rebating (ﬁ g. F)

♦ Fit and adjust the parallel fence. (KW712KA

ONLY)

♦ Proceed as for planing.

Chamfering edges

The V-groove in the nose piece of the shoe

enables you to chamfer edges at 45° angles.

♦ Hold the tool at an angle with the groove

around the edge of the workpiece and perform

the cutting stroke.

Emptying the shavings collection bag

The shavings collection bag should be emptied

regularly while using it.

♦ Unzip the bag and empty it before continuing.

Hints for optimum use

♦ Move the tool along the grain of the wood.

♦ If the grain is cross or curly, or if the workpiece

material is a hard type of wood, adjust the

depth of cut to take only a very thin shaving at

each pass and take several passes to achieve

the desired result.

♦ To keep the tool in a straight line, press down

the front of the tool at the start, and press down

the back of the tool at the end of the cutting

stroke.

Accessories

The performance of your tool depends on

the accessory used. Black & Decker and

Piranha accessories are engineered to high

quality standards and designed to enhance

the performance of your tool. By using these

accessories you will get the very best from your

tool.

The following types of cutting blades can be

obtained from your local retailer:

- Tungsten carbide tipped reversible cutting

blades (part no. X35007, supplied per pair)

- High-speed steel reversible cutting blades (part

no. X24192-XJ11, supplied per pair)
