DM12-01.01.10en Oasis Inverter
Service manual 17
MS11MU-18HRDN1 / MO11MU-18HRDN1
Cooling
Cooling Outdoor conditions (DB)
Indoor Conditions (kW) 18ºC 21ºC 28ºC 35ºC 43ºC
TC 5.70 5.44 5.17 4.91 4.70
21/15ºC DB/WB SC 4.11 4.02 3.98 3.93 3.95
Input 2.73 2.83 3.07 3.21 3.31
TC 5.81 5.60 5.33 5.07 4.75
24/17ºC DB/WB SC 4.24 4.20 4.16 4.11 3.99
Input 2.76 3.00 3.21 3.34 3.51
TC 5.91 5.70 5.44
5.28
4.91
27/19ºC DB/WB SC 4.26 4.22 4.19 4.12 4.03
Input 2.86 3.07 3.24
3.41
3.58
TC 6.02 5.81 5.60 5.49 5.07
32/23ºC DB/WB SC 5.00 4.94 4.87 4.83 4.71
Input 3.07 3.21 3.34 3.58 3.72
Heating
Heating Outdoor conditions
Indoor Conditions
(DB) (kW)
24/18ºC
DB/WB
7/6ºC
DB/WB
2/1ºC
DB/WB
-5/-6ºC
DB/WB
-7/-8ºC
DB/WB
15ºC
TC 7.24 5.85 4.79 4.34 4.07
Input 3.99 3.43 2.95 2.77 2.62
20ºC
TC 7.02
5.57
4.51 4.23 3.90
Input 4.35
3.69
3.25 2.99 2.80
27ºC
TC 6.57 5.24 4.23 4.12 3.68
Input
4.61 3.99 3.51 3.25 3.03
Remark:
TC: Total capacity; kW
SC: Sensible heat capacity; kW
Input: Input power; kW
