7
ENGLISH
(Original instructions)
u If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised Black & Decker Service
Centre in order to avoid a hazard.
Features
1. Blow tube
2. Vac tube
3. Collection bag
4. Blow/Vac
5. On/Off switch
6. Power commander
7. Battery
8. Feet
Assembly
@
Warning! Before assembly, make sure that
the appliance is switched off and the battery is
removed.
@
Warning! Always wear protective gloves when
working with your cordless sweeper.
Blow tube assembly (g. A)
The blow tube (1) must be assembled before use.
u Align the latches (9) on the side of the blow tubes (1).
u Push the blow tube (1) rmly into each other until the
latches (9) click into place.
Note! The tubes should not be separated once assembled.
Vac tube assembly (g. B)
The vac tube (2) must be assembled before use.
u Align the latches (10) on the side of the vac tube (2).
u Push the vac tube (2) rmly into each other until the
latches (10) click into place.
Note! The tubes should not be separated once assembled.
Fitting and removing the battery (g. C)
u To t the battery (7), line it up with the receptacle on the
tool. Slide the battery into the receptacle and push until
the battery snaps into place.
u To remove the battery, push the release button (11) while
at the same time pulling the battery out of the receptacle.
Use
Warning! Let the tool work at its own pace. Do not overload.
Charging the battery (g. D)
The battery needs to be charged before rst use and whenev-
er it fails to produce sufcient power on jobs that were easily
done before. The battery may become warm while charging;
this is normal and does not indicate a problem.
Warning! Do not charge the battery at ambient temperatures
below 10 °C or above 40 °C. Recommended charging tem-
perature: approx. 24 °C.
Note: The charger will not charge a battery if the cell
temperature is below approximately 0 °C or above 40 °C.
The battery should be left in the charger and the charger
will begin to charge automatically when the cell tempera-
ture warms up or cools down.
u To charge the battery (7), insert it into the charger (12).
The battery will only t into the charger in one way. Do
not force. Be sure that the battery is fully seated in the
charger.
u Plug in the charger and switch on at the mains.
The charging indicator (13) will ash green continuously
(slowly).
The charge is complete when the charging indicator (13)
lights green continuously. The charger and the battery can be
left connected indenitely with the LED illuminated. The LED
will change to ashing green (charging) state as the charger
occasionally tops off the battery charge. The charging indica-
tor (13) will be lit as long as the battery is connected to the
plugged-in charger.
u Charge discharged batteries within 1 week. Battery life will
be greatly diminished if stored in a discharged state.
Leaving the battery in the charger
The charger and battery pack can be left connected with the
LED glowing indenitely. The charger will keep the battery
pack fresh and fully charged.
Charger diagnostics
If the charger detects a weak or damaged battery, the charg-
ing indicator (13) will ash red at a fast rate. Proceed as
follows:
u Re-insert the battery (7).
u If the charging indicators continues ashing red at a fast
rate, use a different battery to determine if the charging
process works properly.
u If the replaced battery charges correctly, the original
battery is defective and should be returned to a service
centre for recycling.
u If the new battery gives the same indication as the original
battery, take the charger to be tested at an authorised
services centre.
