![Panasonic CS-C7BKPG / CU-2C19BKP5G [13/92] Specifications are subject to change without notice for further improvement](/views2/1832900/page13/bgd.png)
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
(A) 2 × 15 (B) 2 × 15 2 × 24
FPI 21 19 16
Size (W × H × L) mm 610 × 315 × 25.4 756
719.5
× 609.6 × 44
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS
M60 (290, 410)
Refrigerant (R-22) g (oz) — (A) 840 (29.7)
(B) 820 (28.9)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — (A) 610 (B) 920
Flow Rate l/min — (A) 16.5 (B) 9.5
Inner Diameter mm — (A) 1.7 (B) 1.5
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — (A) 30 µF, 370 VAC
(B) 15 µF, 440 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400 VAC 3.0 µF, 450 VAC
•
