![Panasonic CU-3C20BKP5G [7/92] Specifications are subject to change without notice for further improvement](/views2/1832900/page7/bg7.png)
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 20% AS + Glass Fiber 20%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 29.3 - 26.3 41.75 - 36.80
Rated Output W 15 12
Fan Speed Low rpm 780 - 780 —
Medium rpm 920 - 920 —
High rpm 1,140 - 1,140 795 - 750
SuperHigh rpm 1,250 - 1,250 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Louver Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 1×20
FPI 19 19
Size (W × H × L) mm 610 × 315 × 25.4 687 × 508 × 22
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(350)
Refrigerant (R-22) g (oz) — 890 (31.4)
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — 505
Flow Rate l/min — 17.8
Inner Diameter mm — 1.7
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 30 µF, 440 VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400 VAC 1.0 µF, 430 VAC
•
