5
2 Specifications
MODEL
INDOOR CS-NE9LKE, CS-XE9LKE-5
OUTDOOR CU-NE9LKE
Performance Test Condition EUROVENT
Power Supply
Phase, Hz Single, 50
V 230
Min. Mid. Max.
Cooling
Capacity
kW 0.60 2.50 3.00
BTU/h — — —
kcal/h 520 2150 2580
Running Current A — 2.6 —
Input Power W 120 540 745
Annual Consumption kWh — 270 —
EER
W/W 5.00 4.63 4.03
kcal/hW 4.33 3.98 3.46
Power Factor % — 90 —
Indoor Noise (H / L / QLo)
dB-A 39 / 26 / 23
Power Level dB 55 / - / -
Outdoor Noise (H / L)
dB-A 46 / -
Power Level dB 61 / -
Heating
Capacity
kW 0.60 3.40 5.40
BTU/h — — —
kcal/h 520 2920 4640
Running Current A — 3.5 —
Input Power W 115 730 1.36k
COP
W/W 5.22 4.66 3.97
kcal/hW 4.52 4.00 3.41
Power Factor % — 91 —
Indoor Noise (H / L / QLo)
dB-A 40 / 27 / 24
Power Level dB 56 / - / -
Outdoor Noise (H / L)
dB-A 47 / -
Power Level dB 62 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 3.91 / 1.20 / 3.26
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.13 / 1.29 / 2.43
Max Current (A) / Max Input Power (W) 6.3 / 1.36k
Starting Current (A) 3.5
Compressor
Type Hermetic Motor
Motor Type Brushless (4-poles)
Output Power W 750
Indoor Fan
Type Cross-flow Fan
Material ASG20K1
Motor Type Transistor (8-poles)
Input Power W 47.3
Output Power W 40
Speed
QLo
Cool/Fan rpm 680
Heat rpm 750
Lo
Cool/Fan rpm 750
Heat rpm 800
Me
Cool/Fan rpm 930
Heat rpm 1010
Hi
Cool/Fan rpm 1120
Heat rpm 1230
SHi
Cool/Fan rpm 1180
Heat rpm 1320
