2 Specifications
MODEL
INDOOR CS-HE9JKE
OUTDOOR CU-HE9JKE
Performance Test Condition EUROVENT
Power Supply
Phase, Hz Single, 50
V 230
Min. Mid. Max.
Cooling
Capacity
kW 0.60 2.60 3.00
BTU/h — — —
Kcal/h 520 2240 2580
Running Current A — 2.4 —
Input Power W 120 510 700
Annual Consumption kWh — 255 —
EER
W/W 5.00 5.10 4.29
Kcal/hW 4.33 4.39 3.69
Power Factor % — 92 —
Indoor Noise (H / L / QLo)
dB-A 39 / 26 / 23
Power Level dB 55
Outdoor Noise (H / L)
dB-A 46 / -
Power Level dB 61 / -
Heating
Capacity
kW 0.60 3.60 6.50
BTU/h — — —
Kcal/h 520 3100 5590
Running Current A — 3.2 —
Input Power W 115 690 1.72k
COP
W/W 5.22 5.22 3.78
Kcal/hW 4.52 4.49 3.25
Power Factor % — 94 —
Indoor Noise (H / L / QLo)
dB-A 42 / 27 / 24
Power Level dB 58
Outdoor Noise (H / L)
dB-A 47 / -
Power Level dB 62 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 4.71 / 1.52 / 3.10
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.70 / 1.58 / 2.34
Max Current (A) / Max Input Power (W) 8.0 / 1.72k
Starting Current (A) 3.2
Compressor
Type Hermetic Motor
Motor Type Brushless (4-poles)
Output Power W 750
Indoor Fan
Type Cross-flow Fan
Material ASK30K1
Motor Type Transistor (8-poles)
Input Power W 24.5
Output Power W 30
Speed
QLo
Cool rpm 560
Heat rpm 650
Lo
Cool rpm 660
Heat rpm 750
Me
Cool rpm 880
Heat rpm 990
Hi
Cool rpm 1090
Heat rpm 1230
SHi
Cool rpm 1170
Heat rpm 1230
