2. Specification
Indoor CS-NE9NKE CS-XE9NKE-5 CS-QE9NKE CS-WE9NKE
Model
Outdoor CU-NE9NKE CU-QE9NKE
Performance Test Condition EUROVENT
Phase, Hz Single, 50
Power Supply
V 230
Min. Mid. Max.
kW 0.85 2.50 3.00
BTU/h 2900 8530 10200
Capacity
kcal/h 730 2150 2580
Running Current A — 2.5 —
Input Power W 170 515 710
Annual Consumption kWh — 258 —
W/W 5.00 4.85 4.23
BTU/hW 17.06 16.56 14.37
EER
kcal/hW 4.29 4.17 3.63
Power Factor % — 90 —
dB-A 39 / 26 / 23
Indoor Noise (H / L / QLo)
Power Level dB 55 / 42 / 39
dB-A 46 / - / -
Cooling
Outdoor Noise (H / L / QLo)
Power Level dB 61 / - / -
kW 0.85 3.40 5.40
BTU/h 2900 11600 18400
Capacity
kcal/h 730 2920 4640
Running Current A — 3.3 —
Input Power W 165 700 1.31k
W/W 5.15 4.86 4.12
BTU/hW 17.58 16.57 14.05
COP
kcal/hW 4.42 4.17 3.54
Power Factor % — 92 —
dB-A 40 / 27 / 24
Indoor Noise (H / L / QLo)
Power Level dB 56 / 43 / 40
dB-A 47 / - / -
Heating
Outdoor Noise (H / L / QLo)
Power Level dB 62 / - / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 3.91 / 1.16k / 3.37
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.33 / 1.29k / 2.58
Max Current (A) / Max Input Power (W) 7.8 / 1.74k
Starting Current (A) 3.3
Type Rotary Motor
Motor Type Brushless (4-poles)
Compressor
Output Power W 900
