LG MDS714 [22/24] Specifications
![LG MDS714 [22/24] Specifications](/views2/1083647/page22/bg16.png)
22
Designs and specifications are subject to change without prior notice.
Specifications
General
Power supply Refer to main label.
Power consumption Refer to main label.
Net Weight MDS714: 6.1 kg MDT364: 6.0 kg MDD264: 6.0 kg
External dimensions (W x H x D) 273 x 337 x 340 mm
Operating conditions Temperature: 5°C to 35°C, Operation status: Horizontal
Operating humidity 5% to 85%
Tuner
FM Tuning Range 87.5 - 108.0 MHz or 87.50 - 108.00 MHz
Intermediate Frequency 128 KHz
AM Tuning Range 522 - 1,620 KHz or 522 - 1,710 KHz or 520 - 1,710 KHz
Intermediate Frequency 45 KHz
Amplifier
OUTPUT POWER Front: 130 W + 130 W (4 Ω, THD 10 %)
Rear : 90 W + 90 W (6 Ω, THD 10 %)
Center : 90 W (6 Ω, THD 10 %)
Subwoofer: 180 W (3 Ω, THD 10 %)
DVD/CD player
Frequency response (audio) 40 - 20000 Hz
Signal-to-noise ratio (audio) More than 75 dB (1 kHz)
Signal-to-noise ratio (video) More than 55 dB (1 kHz)
Dynamic range (audio) More than 80 dB
Video output 1.0 V (p-p), 75 Ω
Component Video output (Y) 1.0 V (p-p), 75 Ω
(Pb)/(Pr) 0.7 V (p-p), 75 Ω
Speakers
MDS264V
MDS364V MDS364W
MDS714V MDS714C MDS714S MDS714W
Front Speaker
Center Speaker Rear Speaker Subwoofer
Type 2 Way 2 Speaker
1 Way 1 Speaker 2 Way 2 Speaker 1 Way 1 Speaker
Impedance 4 Ω 6 Ω
6 Ω 3 Ω
Rated Input Power
130 W (MDS364V: 100 W)
90 W 90 W
180 W (MDS364W: 160 W)
Max. Input Power
260 W (MDS364V: 200 W)
180 W 180 W
360 W (MDS364W: 320 W)
Net Dimensions (W x H x D)
237 x 429 x 299 mm 274 x 148 x 202 mm 212 x 334 x 232 mm 274 x 333 x 391 mm
Net Weight (1 EA) 5.7 kg 2.4 kg 3.3 kg 6.8 kg
Cassette tape player
F.F/REW Time 120 sec (C-60)
Frequency Response 250 - 8000 Hz
Signal to Noise Ratio 43 dB
Channel Separation 50 dB (P/B)/45 dB (R/P)
Erase Ratio 55 dB (MTT-5511)
MDS714-A0U_DKENHL_ENG_8476.indd 22 2009.3.3 9:57:51 AM
