Citizen CL-E720DT [3/91] Introduction
![Citizen CL-E720DT [3/91] Introduction](/views2/1842817/page3/bg3.png)
3
■■■
Main Features
■■■
<High-speed, high-quality printing>
This printer can be used for high-speed, high-quality printing thanks to its ARM® Cortex-A9
processor and Citizen’s history control IC.
*ARM and Cortex are registered trademarks or trademarks of ARM Limited.
<Environment-friendly energy-ecient design>
As an energy-ecient product, this printer is compliant with the International Energy Star
Program (ENERGY STAR®).
<Optimal ribbon tension through ARCP
TM
>
Designed to provide the optimal ribbon tension from the beginning to the end of the ribbon
roll, the ARCP
TM
technology insures stable printing position & printed output accuracy by
preventing ribbon slippage and ribbon wrinkle.
<Easy control language>
Label creation and printing is easily accomplished through the use of printer control
language emulations. This printer can process either ZPL
TM
or DPL
TM
as standard.
<Easy operation>
• The printer status can be seen easily and its conguration & setup adjusted easily using
the graphic LCD panel.
• The high-lift printhead and mechanism means that media and ribbon can be loaded with
ease and it is constructed for easy thermal printhead cleaning, etc.
• Media width adjustment, media thickness adjustment, media sensor adjustment, and
ribbon tension adjustment can all be accomplished easily by the user using the colour-
coded operator controls.
<Interface>
Ethernet (LAN) and USB 2.0 are standard equipment, for quick data transfer and printing.
<Optional interface>
Optional RS232C Serial, IEEE1284 Parallel and Wireless LAN (WiFi) are all quickly installed.
<Optional auto-cutter / peeler unit>
The auto-cutter and peeler units are designed so that they can be installed easily.
INTRODUCTION
Thank you for purchasing the CITIZEN CL-E720/CL-E730 printer. This printer is compatible with the maximum
media width (118 mm or 4.65 inch), which has been developed for a wide range of applications such as
labels, tags and tickets.
