Specifications
Model CT-P291 CT-P293 CBM-920 II
Printing method Line thermal dot printing Serial dot impact
Printing width 54mm,432dots 72mm,576dots 57.5mm
Printing speed Max.150mm/sec 24col=2.5lines/sec
Number of columns FontA:34columns FontA:48columns 24/40columns
FontB:45columns FontB:64columns
FontC:51columns FontC:72columns/Max54columns
Character size (WxH) FontA:1.25x3.00mm(12x24dots) 24col=1.62x2.4mm
FontB:0.88x2.13mm(9x17dots) 40col=1.08x2.4mm
FontC:1.00x2.00mm(8x16dots)
Dot pitch/Character pitch 24col=1.98mm 24col=1.98mm
40col=1.19mm
Barcode type UPC-A/E,JAN(EAN)-13/8columns,ITF,Code39,Code128,CODABAR,CODE93,PDF417,
QRCode
Line spacing 4.25mm(1/6inch);canbesetbyacommand. Character=3.52mm
Graphic2.4mm
Paper 58xMax.Ø50mm 80xMax.Ø50mm 57.5
Interface Parallel (Centronics), Serial(RS-232C),USB Parallel (Centronics),
Serial(RS-232C)
Input buffer 4Kbytes/45Bytes 2kbytes
Power supply Inputvoltage:DC24V±10%,Currentconsumption:1.9A(9Aatpeak) DC/V
Weight Approx.700g Approx.800g 0.47kg
Dimensions (W x D x H) 107x120.5x109mm 127x120.5x109mm 106x180x88mm
Operating temp. ranges -20~50°C,10to85%RH(Nocondensation)  0to40°C
Storage temp. range -20~60°C,10to90%RH(Nocondensation) -20-60°C
Reliability Thermalhead100,000,000pulsesor100KM Printer:1.5millionlines
Autocutter1millioncuts
EMC and safety standards UL,C-UL,FCCclassA,TÜV-Bauart,CEmarking FCCclassB
Mettinger S t r a ß e 11 • D-73728 E s s l i n g e n Germany • Tel.: + 4 9 (0)711/3906-400 • Fax: + 4 9 (0)711/3906-405 • www.citizen-europe.com
Features
CT-P291/CT-P293
• Compactdesign
• Panelmounting
• 150mm/sec.printingspeed
• Easydrop-inpaperloading
• 1Dand2Dbarcodeprinting
• ESC/POScompatibility
• Autocutter
• Lowtemperatureoperationdown
to -20°C
• Splash-proofdesign(JISClass1)
• DC24Vdrive
• Parallel,serialandUSBinterface
CBM-920 II
• PalmsizeandLightweight
• Bitimagegraphicsprinting
• Memoryswitchfunction
• 2Kbytesinputbuffer
• Panelmount
• Paper-near-endsensor
• Paperautoloading
• Paper-endsensor
58
80
Paper Roll
Paper Roll
mm
mm
58
80
Paper Roll
Paper Roll
mm
mm
Type Classification
1) Model type 2) Number of columns 3) Interface 4) Character set 5) Power source
CBM-920 Type II
24: 24 columns/144 dots
40: 40 columns/180 dots
P: Parallel (Centronics)
R: Serial (RS-232C)
F: International
DC: DC 5V
CBM-920II-24RF230
1) 2)3)4)5)
1) Model type 2) Interface 3) Market 4) Body case colour 5) Wiring cable
CT-P291 (58mm)
CT-P293 (80mm)
AL: (Serial + Parallel + USB)
U: (international) WH: White NN: standard harness type
DC: Hoshiden connector type
CT-P291ALUWHNN
1)2)3)4) 5)
Designs,specificationsandavailabilityaresubjecttochangewithoutnotice.Errorsandomissionsexcluded.
