FUNCTION

FUNCTION SWITCH

· Position RADIO for:

- Radio reception

- Recording from radio on deck B

· Position DUBBING for:

- Synchronized dubbing from tape A to tape B

· Position to TAPE for:

- Switching off the radio

- Cassette playback

SOUND ADJUSTMENT

VOLUME

The level of sound reproduced by the loudspeaker or Stereo Headphones is adjusted by the VOLUME control.

NOTE:

During recording, adjusting the VOLUME control only affects the monitor sound and not the content of recording.

RADIO OPERATION

OPERATION

· Set Function switch to RADIO position thus the Power LED indicator should light up.

· Select your desired broadcasting band with Band switch.

· Rotate the Tuning control regulator to receive the desired broadcast.

· Adjust the level of sound with Volume control switch.

· To turn off the radio, set the Function switch to TAPE position.

ANTENNA

· For FM reception, adjust the telescopic antenna appropriately to obtain the best reception on the band selected.

· The AM signals are picked up through the built-in ferrite antenna. The set should be placed to a position for the best reception.

FM AND FM STEREO RECEPTION

Set the FUNCTION switch to the FM STEREO position. This is the ideal setting to listen to FM Stations as it will provide Stereo Sound. If the

reception is weak, the FUNCTION Switch can be set to FM MONO. The reception will be stronger but the quality of sound will not be that of FM

STEREO.
