TROUBLESHOOTING

Carefully re-read the instructions to make sure the unit is being operated properly.

Check the following before you take your unit to the local dealer for repair.

SYMPTOM CAUSE

There is no sound from the speakers. - Headphones are connected to the unit.

- The Volume control is set too low.

The radio does not work The FUNCTION switch is in the TAPE position

There is excessive static during FM reception. The antenna is not properly positioned

A cassette cannot be inserted into the compartment. The tape is inserted in the wrong direction.

The PLAY button does not lock in position after inserting cassette

tape

The tape is at its end and auto-stop function is in operation.

The RECORD button cannot be pressed down with a cassette tape

inside.

A tape with its safety tab removed has been inserted.

The TAPE does not play The PAUSE button is depressed.

The sound is weak or distorted during tape playback. The record/playback head is dirty.

A previous recording cannot be completely erased. The erase head is dirty.

If you find the unit is not working properly after checking the above chart, please take it to your nearest Services Center. Do not attempt to

repair it by yourself. Refer all servicing to qualified service personnel. If necessary, clean the unit with a piece of cloth dampened with water

only. Make sure the unit is disconnected from an AC power outlet.

SPECIFICATION

Power supply 220 V, 50 Hz

RMS 2.5 W  2

Net / Gross Weight 2.066 kg / 2.4 kg

Gift box dimension (L x W x H) 518 mm x 142 mm x 165 mm
