Hitachi DS10DFL [11/80] English

English

When the shift knob is set to “LOW”, the drill rotates

at a low speed. When set to “HIGH”, the drill rotates

at a high speed.

CAUTION

䡬 When changing the rotational speed with the shift

knob, confirm that the switch is off.

Changing the speed while the motor is rotating will

damage the gears.

䡬 When setting the shift knob to “HIGH” (high speed)

and the position of the clutch dial is “17” or “21”, it

may happen that the clutch does not engaged and

that the motor is locked. In such a case, please set the

shift knob to “LOW” (low speed).

䡬 If the motor is locked, immediately turn the power

off. If the motor is locked for a while, the motor or

battery may be burnt.

4. The scope and suggestions for uses

The usable scope for various types of work based on

the mechanical structure of this unit is shown in

Table 2.

CAUTION

䡬 The selection examples shown in Table 3 should be

considered as general standard. As different types of

tightening screws and different materials to be

tightened are used in actual works proper adjustments

are naturally necessary.

䡬 When using the driver drill with a machine screw at

HIGH (high speed), a screw may damage or a bit may

loose due to the tightening torque is too strong. Use

the driver drill at LOW (low speed) when using a

machine screw.

NOTE:

The use of the battery BCL1015 in a cold condition

(below 0 degree Centigrade) can sometimes result in

the weakened tightening torque and reduced amount

of work. This, however, is a temporary phenomenon,

and returns to normal when the battery warms up.

6. Mounting and dismounting of the bit

(1) Mounting the bit

After inserting a driver bit, etc. into the keyless drill

chuck, firmly grasp the ring and tighten the sleeve by

turning it toward the right (in the clockwise direction

as viewed from the front) (See Fig. 10).

䡬 If the sleeve becomes loose during operation, tighten

it further. The tightening force becomes stronger

when the sleeve is tightened additionally.

(2) Dismounting the bit

Firmly grasp the ring and loosen the sleeve by turning

it toward the left (in the counter-clockwise direction

as viewed from the front) (See Fig. 10).

CAUTION

䡬 When it is no longer possible to loosen the sleeve, use a

vise or similar instrument to secure the bit. Set the

clutch mode between 1 and 13, and then turn the

sleeve to the loose side (left side) while operating the

clutch. It should be easy now to loosen the sleeve.

7. Confirm that the battery is mounted correctly

8. Check the rotational direction

The bit rotates clockwise (viewed from the rear side)

by pushing the R-side of the selector button.

The L-side of the selector button is pushed to turn the

bit counterclockwise (See Fig. 6) (The

and

marks are provided on the body).

9. Switch operation

䡬 When the trigger switch is depressed, the tool rotates.

When the trigger is released, the tool stops.

Work Suggestions

Wood

Drilling Steel Use for drilling purpose.

Aluminum

Machine screw Use the bit or socket matching the screw diameter.

Driving

Wood screw Use after drilling a pilot hole.

Table 2

5. How to select tightening torque and rotational speed

Table 3

Use

Clutch Dial

Rotating speed selection (Position of the shift knob)

Position

LOW (Low speed) HIGH (High speed)

Machine screw 1 – 21

For 4 mm or smaller diameter

screws.

Driving

Wood screw

1 –

For 5.8 mm or smaller nominal

diameter screws.

Wood

For 21 mm or smaller

diameters.

Driling

Metal

For drilling with a metal

working drill bit.

For 6 mm or smaller

diameter screws.

For 3.8 mm or smaller

nominal diameter screws.

For 12 mm or smaller

diameters.

01Eng_DS10DFL_EE 10/4/30, 09:5010
