- 8
Subject to technical modifications!
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
Alfred Kärcher GmbH Co. KG
Alfred-Kärcher-Str. 28 - 40
71364 Winnenden (Germany)
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Technical specifications
Water connection
Max. feed temperature °C 40
Min. feed volume I/min 10
Max. feed pressure MPa 1,2
Max. Suction height m 0,5
Electrical connection
Voltage
1~50 Hz
V230
Connected load kW 1,9
Mains fuse (slow-blow) A 10
Protective class I
Protection class IP X5
Performance data
Working pressure MPa 12
Max. permissible pressure MPa 14
Water flow rate I/min 6,7
Dimensions and weights
Length mm 372
Width mm 355
Height mm 902
Weight, ready to operate
with accessories
kg 17,1
Detergent flow rate I/min 0,3
Recoil force of trigger gun N 15
Values determined as per EN 60335-2-79
Hand-arm vibration value
Uncertainty K
m/s
2
m/s
2
< 2,5
0,3
Sound pressure level L
pA
Uncertainty K
pA
dB(A)
dB(A)
73
2
Sound power level L
WA
+
Uncertainty K
WA
dB(A) 88
CE declaration
Product: High-pressure cleaner
Type: 1.636-xxx
Relevant EU Directives
2006/42/EC (+2009/127/EC)
2004/108/EC
2000/14/EC
Applied harmonized standards
EN 60335–1
EN 60335–2–79
EN 55014–1: 2006
EN 55014–2: 1997 + A1: 2001
EN 61000–3–2: 2006
EN 61000–3–3: 2008
EN 50366: 2003 + A1: 2006
Applied conformity evaluation method
Appendix V
Sound power level dB(A)
Measured: 86
Guaranteed: 88
CEO
Head of Approbation
20 EN
