LG L177WSB-PF [20/22] Specifications
![LG L177WSB-PF [20/22] Specifications](/views2/1085065/page20/bg14.png)
A19A19
Specifications
NOTE
Information in this document is subject to change without notice.
Display
Sync Input
Video Input
Resolution
Plug&Play
Power
Consumption
Dimensions
&Weight
Tilt Range
Power Input
Environmental
Conditions
Stand Base
Power cord
17 inches (43.3 cm) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
17 inches viewable
0.255*0.255 mm pixel pitch
Horizontal Freq. 30 - 83 kHz (Automatic)
Vertical Freq. 56 - 75 Hz (Automatic)
Input Form Separate TTL, Positive/Negative
SOG (Sync On Green)
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Max VESA 1440 x 900 @75 Hz
Recommend VESA 1440 x 900 @60 Hz
DDC 2B
On Mode
: 23 W(Typ.)
Sleep Mode ≤ 1 W
Off Mode ≤ 1 W
With Stand Without Stand
Width 40.93 cm / 16.11 inches 40.93 cm / 16.11 inches
Height 36.20 cm / 14.25 inches 31.00 cm / 12.20 inches
Depth 20.40 cm / 8.03 inches 7.40 cm / 2.91 inches
Net 2.80 kg (6.17 lbs)
Tilt -5˚~20˚
AC 100-240V~ 50/60Hz 0.8A
Operating Conditions
Temperature 10˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Attached( ), Detached ( O )
Wall-outlet type or PC-outlet type
