LG L177WSB-PF [9/22] Control panel functions

Control Panel Functions

This Indicator lights up blue when the display

operates normally(On Mode). If the display is in Sleep

Mode (Energy Saving), this indicator color changes

to amber.

Use this button to turn the display on or off.

Power Button

Power Indicator

Use this button to enter a selection in the On Screen

Display.

SET Button

Buttons

Use these buttons to select or adjust functions in the On

Screen Display.

For more information, refer to page A15.
