2
G Operating instruction
Thank you for choosing aHama product.
Take your time and read the following instructions and information completely.Please keep
these instructions in asafe place for futurereference. If you sell the device, please pass
these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic
hazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
• TV wall bracket
• TV support arms (2x)
• Support arms cover (6x)
• Wall plate cover (2x)
• Drilling template
• Installation kit (see contents, Fig. 1)
• These operating instructions
Note
Please check that the installation kit is complete beforeinstalling the bracket and ensure
that none of the parts arefaulty or damaged.
3. Safety Notes
Warning
• Given the multitude of terminal devices and wall structures available on the market,
the supplied mounting kit is unable to cover every option.
• It occasionally happens that the screws for attaching the terminal device to the wall
bracket aretoo long.
• Please note that the supplied wall plugs arefor use with concrete brick and solid
brick walls only.
• Read the operating instructions for your terminal device beforeattempting to mount
it. The instructions provide information about the type and measurements of suitable
fastening materials.
• If the supplied mounting kit does not contain suitable fastening materials for
mounting the terminal device, purchase these from aspecialised dealer.
•
If the wall on which the bracket is to be mounted is made of different material types
and construction types to those specied, purchase suitable mounting materials from a
specialised dealer.
• Never apply force during mounting. This can damage your end device or wall
bracket.
• If in doubt, have this product mounted by aqualied technician -donot attempt to
mount it yourself!
• Do not mount the product above locations wherepersons might linger.
• Once you have mounted the product and the attached load, check that they are
suciently secureand safe to use.
• Youshould repeat this check at regular intervals
(at least every three months).
• When doing so, ensurethat the product does not exceed its maximum permitted
carrying capacity and that no load exceeding the maximum permitted dimensions is
attached.
• Make surethat the product is loaded symmetrically.
• During adjustment, ensurethat the product is loaded symmetrically and that the
maximum permitted carrying capacity is not exceeded.
• Maintain the necessary safety clearance around the attached load (depending on the
model).
• In the event of damage to the product, remove the attached load and stop using the
product.
4. Intended use and specifications
• The bracket is used for wall mounting at panel displays for non-commercial, private
household use.
• The bracket is only intended for use within buildings.
• Use the bracket only for the intended purpose.
Maximum load bearing capacity: 75 kg
Screen size:
117.0 -229.0 cm (US: 46” -90”)
Depth: 5,5 -44,9 cm
Angle: -10°/+2° (depends on the device)
Pivoting range:
Up to 120° at 3hinges with 2double
carrier arms (depends on the device)
Wall mounting plate dimensions: 47.7 x35.9 cm
Mounting holes: according to the VESA standarduntil: 800x600
5. Installation requirements and installation
Note
• Only mount the TV wall bracket with the help of asecond person. Get the support
and help you need.
• Different end devices have different options for connecting cables and other devices.
Beforeinstallation, ensurethat the necessary connections will still be accessible
after installation.
• The same mounting kit is included with all of our TV wall brackets. Depending on
the product and mounting type, you may not need to use the entiremounting kit.
Unneeded screws and other small parts may be left over,even if the wall bracket
is properly mounted. Keep these leftover parts with the operating instructions in a
safe place, just in case you might need them later on (e.g. should you move, sell the
product, mount the wall bracket in adifferent location, buy anew TV,etc).
Warning
• This product is suitable for wall mounting only.
• Beforeinstalling the bracket, ensurethat the wall on which the television is to be
mounted is suitable for the weight and make surethat no electrical wires, water,gas
or other lines arelocated at the installation location.
• Please note that the provided wall anchors areonly approved for concrete and solid
brick walls.
• Observe the other warnings and safety instructions.
• Proceed step-for-step in accordance with the illustrated installation instructions (Fig.
1ff.).
• During installation, the hinges aretobeadjusted so that the TV can be moved side-
to-side.
• Check whether your television is level using the included spirit level. If necessary,adjust
the television plate.
Note
• Given the multitude of terminal devices available on the market, we cannot describe
all possible mounting options here.
• Please ensurethat the bracket lays at and evenly on the back of the television.
• Use the enclosed spacer to even out any unevenness on the back of the television.
• Ensurethat all screws have the proper length and can be mounted until they are
hand-tight (see Fig. 4).
6. Setting and maintenance
Note
Only adjust the TV wall bracket with the help of asecond person. Get the support and
help you need.
• Screws do not have to be loosened to adjust the angle.
• Check that the bracket is secureand safe to use at regular intervals (at least every three
months). Only use water or standardhousehold cleaners for cleaning.
• Pull the safety corddownwards for securing, hang the carrier arms in the wall plate and
let snap into place by releasing (g. 6).
7. Warranty Disclaimer
Hama GmbH &CoKG assumes no liability and provides no warranty for damage resulting
from improper installation/mounting, improper use of the product or from failuretoobserve
the operating instructions and/or safety notes.
