ENGLISH en
11
until it cannot be turned any further - only now is the
tool securely clamped.
With a soft tool shank, retightening may be required
after a short drilling period.
Open the chuck:
Hold the retaining ring (a) firmly and turn the collet
(b) towards "AUF, RELEASE" with the other hand.
Note: The grating sound which may be heard after
opening the drill chuck is functional and is stopped
by turning the sleeve in the opposite direction.
If the chuck is very securely tightened: Unplug.
Hold the drill chuck using an open-end spanner at
the flats on its head, and turn the sleeve (b)
vigourously in the direction of "AUF, RELEASE".
Quick-action keyless chuck with plastic sleeve:
See illustrations on page 2.
Insert the tool. Hold the retaining ring (a) firmly and
turn the collet (b) towards "GRIP, ZU" with the other
hand until it will not turn any further.
With a soft tool shank, retightening may be required
after a short drilling period.
Open the chuck:
Hold the retaining ring (a) firmly and turn the collet
(b) towards "AUF, RELEASE" with the other hand.
If the chuck is very securely tightened: Unplug.
Hold the drill chuck using an open-end spanner at
the flats on its head, and turn the sleeve (b)
vigourously in the direction of "AUF, RELEASE".
7.8 Tool Change With
Geared Chuck (2)
See illustrations on page 2.
Clamping tools:
Insert the tool and clamp evenly in all 3 holes using
the chuck key (1).
Removing tools:
Open the geared chuck (2) using the chuck key (1)
and remove the tool.
7.9 Removing the Chuck
B 650, BE 650, SB 650, SBE 650, SBE 650 Impuls:
The chuck can be removed to insert a screwdriver
bit. Insert the bit directly in the hexagon socket on
the spindle.
The screwdriver bit is retained if a bit clamping bush
(as an accessory: order no. 6.31281)
is fitted.
Futuro Plus keyless chuck
See page 4, illustration A.
Unscrew the safety screw - if available. Caution:
left-handed thread!
Hold the drill spindle securely using an open-end
wrench. Clamp an Allen key in the chuck and strike
lightly with a rubber hammer to loosen, then
unscrew.
Geared chuck
See page 4, illustration B.
Unscrew the safety screw - if available. Caution:
left-handed thread!
Hold the drill spindle securely using an open-end
wrench. Insert the key in the chuck and strike lightly
with a rubber hammer to loosen, then unscrew.
Keyless chuck cleaning:
After prolonged use hold the chuck vertically, with
the opening facing down, and fully open and close it
several times. The dust collected falls from the
opening. Regular use of cleaning spray on the jaws
and jaw openings is recommended.
f
Use only genuine Metabo accessories.
Use only accessories which fulfil the requirements
and specifications listed in these operating instruc-
tions.
Fit accessories securely. Secure the machine if it is
operated in a bracket. Loss of control can cause
personal injury.
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out by
qualified electricians ONLY!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. For
addresses see www.metabo.com.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline 2012/
19/EU on used electronic and electric
equipment and its implementation in national legal
systems, used power tools must be collected
separately and handed in for environmentally
compatible recycling.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
P
1
=Nominal power input
P
2
=Power output
n
0
=No load speed
n
1
=Speed at rated load
s max. =Max. impact rate
ø max. =Max. solid drill diameter
G =Drill spindle thread
H =Drill spindle with hexagon socket
m =Weight without mains cable
D =Collar diameter
8. Maintenance
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical Specifications
