![LG 14D1RB [19/28] Sound adjustment option](/views2/1085631/page19/bg13.png)
Sound adjustment (option)
Sound output selection
(option)
In AV mode, you can select output sound for the left and right loud-
speakers.
Repeatedly press the I/II/
*
button to select the sound output.
L+R : Audio signal from audio L input is sent to left loud-speaker
and audio signal from audio R input is sent to right loud-
speaker.
L+L : Audio signal from audio L input is sent to left and right loud-
speakers.
R+R : Audio signal from audio R input is sent to left and right
loud-speakers.
Stereo/Dual reception
(option)
When a programme is selected, the sound information for the sta-
tion appears after the programme number and station name disap-
pear.
Mono sound selection
In stereo reception if the stereo signal is weak, you can switch to
mono by pressing the I/II/
*
button twice. In mono reception the
depth of sound is improved. To switch back to stereo, press the
I/II/
*
button twice again.
Language selection for dual language broadcast
If a programme received in two languages (dual language), you can
switch to DUAL I, DUAL II or DUAL I+II by pressing the I/II/
*
but-
ton repeatedly.
DUAL I sends the primary broadcast language to the loudspeakers.
DUAL II sends the secondary broadcast language to the loud-
speakers.
DUAL I+II sends a separate language to each loudspeaker.
NICAM reception (option)
If your set is equipped with the receiver for NICAM reception, the
high quality NICAM (Near Instantaneous Companding Audio
Multiplex) digital sound can be received.
Sound output can be selected according to the type of received
broadcast as follows by pressing the I/II/
*
button repeatedly.
1. When NICAM mono is received, you can select NICAM
MONO
or FM MONO.
2. When NICAM stereo is received, you can select NICAM
STEREO
or FM MONO. If the stereo signal is weak, switch to
FM mono.
3. When NICAM dual is received, you can select NICAM DUAL
I
, NICAM DUAL II or NICAM DUAL I+II or MONO. When
FM mono is selected the display MONO appears on the
screen.
I / II /
19
Broadcast
Mono
Stereo
Dual
On Screen Display
MONO
STEREO
DUAL I
