16 English
Subject to technical modifications!
We hereby declare that the machine de-
scribed below complies with the relevant
basic safety and health requirements of the
EU Directives, both in its basic design and
construction as well as in the version put
into circulation by us. This declaration shall
cease to be valid if the machine is modified
without our prior approval.
The undersigned act on behalf and under
the power of attorney of the company man-
agement.
Alfred Kärcher GmbH Co. KG
Alfred Kärcher-Str. 28 - 40
D - 71364 Winnenden
Phone: +49 7195 14-0
Fax: +49 7195 14-2212
Specifications
Power connection
Voltage (1~50 Hz) 220-240 V
Connected load 2,5 kW
Mains fuse (slow-blow) 16 A
Maximum allowed net im-
pedance
0,388
+j0,243
Ω
Ω
Protective class I
Protection class IP X5
Water connection
Max. feed temperature 60 °C
Min. feed volume 10 l/min
Max. feed pressure 0,6 MPa
Performance data
Working pressure 13 MPa
Max. permissible pressure 14 MPa
Water flow rate 8,8 l/min
Detergent flow rate 0,2 l/min
Recoil force of trigger gun 21 N
Hand-arm vibration
(ISO 5349)
0,8 m/s
2
Sound pressure level
L
pA
(EN60704-1)
73 dB(A)
Sound power level
L
WA
(2000/14/EG)
92 dB(A)
Dimensions
Length 400 mm
Width 395 mm
Height 925 mm
Weight 19 kg
CE declaration
Product: High-pressure cleaner
Type: 1.397-xxx
Relevant EU Directives
98/37/EC
2006/95/EC
89/336/EEC (+91/263/EEC, 92/31/EEC,
93/68/EEC)
2000/14/EC
Applied harmonized standards
EN 55014–1: 2000 + A1: 2001 + A2: 2002
EN 55014–2: 1997 + A1: 2001
EN 60335–1
EN 60335–2–79
EN 61000–3–2: 2000 + A2: 2005
EN 61000–3–11: 2000
Applied conformity evaluation method
Appendix V
Sound power level dB(A)
Measured: 90
Guaranteed: 92
