9
PRODUCT CERTIFICATION
For information on product certication, see http://www.oursson.com or ask seller for a copy.
The kettle is equipped with protection from
switch-on without water. If you turn on the
kettle with no water or a little water, the
device will turn o after a few seconds. Af-
ter cooling the heating element, the kettle
will get back to working condition. Clicking
sounds made by the kettle, indicate the reset
of thermostat.
To accelerate the cooling of the heating ele-
ment, do not ll kettle with cold water. This
may damage the heating element.
Kettle is designed only for heating clean drinking water.
BEFORE FIRST USE:
• Wash the inner surface of your new kettle with the
use of non-abrasive cleaners. Dry the kettle. Wipe
the kettle with a clean dry cloth.
• Boil the maximum amount of water in a safe manner
as described in the previous section. Monitor for no
leaks, sparks, melting of body, stand, excessive heat-
ing of the power cord, plug, and burning smell during
rst two boiling.
• Boiled water from the rst two boiling is not recommend-
ed to use in food. You can use it for everyday needs.
OPERATION ORDER:
Boiling the water:
1. Remove the kettle from the base, open the lid (Pic.
C-2), and ll it with water.
2. Install the kettle cover to would fall into the bore with a
protrusion, and the cover will t snugly onto the kettle.
Place the kettle on a stand. Insert the plug into an outlet.
3. Push
5
button down. Water will heat up.
4. After boiling the water, the kettle will automatically turn o.
Turning o the kettle
There are two ways of turning o the kettle:
• Push
5
button up, when the device is working;
• When the kettle is working, remove it from the stand.
CLEANING AND MAINTENANCE, Рiс. D
Hard water can leave scale in the kettle. Use special
cleaners for descaling. Follow the instructions of the used
detergent. Do not use abrasive or harsh cleaners.
• Fill the kettle halfway with water.
• For every 2 cups of water, add 6 tablespoons of white
vinegar 8%.
• Bring to a boil.
• Repeat the procedure if necessary.
• Unplug it.
• Allow the kettle to cool and rinse it twice with cold water.
• Wipe the outside of the kettle with a clean, soft,
damp cloth. In order to prevent electrical shock
do not immerse the entire product or the wires
into the water.
Thoroughly dry all the parts of the device.
While utilizing the kettle, the heating element
can change the color, but that will not aect
the kettle’s work.
Specications
Model EK1742G
Power consumption, W max 1800
Rated voltage 220-240V~; 50-60 Hz
Level of protection I
Storage and transportation temperature from -25°C to +35°C
Operating temperature from +5°C to +35°C
Humidity requirements 15-75%
Dimensions, mm 256x159x192
Weight, kg 1,62
Body material Ceramic
Swivel base 360 °C
Protection against switching on without water yes
Controller Strix
Auto / manual shutdown mode Stainless steel
Power indicator light yes
Water level indication max
Volume, L 1
*Products should be stored in dry, ventilated warehouses at temperatures below - 25°С.
Reparation must be performed only by a qualied personnel authorized by OURSSON AG service center.
