- 8
The scope of delivery of your appliance is il-
lustrated on the packaging. Check the con-
tents of the appliance for completeness
when unpacking.
In the event of missing accessories or any
transport damage, please contact your
dealer.
Illustrations on Page 4
1 Water connection
2 Fine filter in the water
connection
3 Coupling element for water connection
4 Quick coupling for high pressure hose
5 High pressure connection
6 Appliance switch "0/OFF“/ „I/ON“
7 Detergent Tank
8 Dosage regulator for detergent
9 Storage for trigger gun
10 Detergent suction hose (with filter)
11 Transport handle
12 Storage for high-pressure hose
13 Storage for accessories
14 Mains cable with mains plug
15 Bearing wheel
16 Lock trigger gun
17 Trigger gun
18 Key to detach the high-pressure hose
from the trigger gun
19 High pressure hose
20 Washing brush
21 Spray lance with Dirtblaster
22 Spray lance with pressure regulation
(Vario Power)
Special accessories expand the possibilities
of using your appliance. Please contact your
KÄRCHER dealer for further information.
Mount loose parts delivered with appliance
prior to start-up.
Illustrations on fold-out
pages!
Illustration
Î Insert the transport handle and screw in.
Î Insert holder for trigger gun.
Illustration
Î Connect the suction hose for detergent
to the dosage regulator.
Illustration
Î Lock the dosage regulator for detergent
into the cover.
Illustration
Î Insert the cover and screw in.
Illustration
Î Pull the suction hose for detergent
through the cover of the detergent tank
until the filter contacts teh bottom of the
tank.
Illustration
Î Close the detergent tank with the lid.
Î Lock the detergent tank in place on the
appliance.
Illustration
Î Attach the accessories holder.
Illustration
Î Fasten the quick coupling for the high
pressure hose to the high pressure con-
nection.
According to the applicable regula-
tions, the appliance must never be
used on the drinking water supply
without a system separator. Use a
suitable system separator manufactured by
KÄRCHER; or, as an alternative, a system
separator as per EN 12729 Type BA. Water
flowing through a system separator is con-
sidered non-drinkable.
Caution
Always connect the system separator to
the water supply, never directly to the appli-
ance!
Operation
Scope of delivery
Description of the Appliance
Special accessories
Before Startup
Water supply
17EN
