Removing and installing components

NOTE: The images in this document may differ from your computer depending on the configuration you ordered.

Topics:

• Recommended tools

• Screw list

• Stand

• Cable cover—optional

• Back cover

• Hard drive

• Camera assembly

• Bottom cover

• Heat sink

• Processor

• Rear-I/O bracket

• System board

• Speakers

• Power-button board

• Microphones

• Side I/O-board

● Phillips screwdriver #1

● Plastic scribe

Screw list

NOTE:

When removing screws from a component, it is recommended to note the screw type, the quantity of screws, and

then place them in a screw storage box. This is to ensure that the correct number of screws and correct screw type is

restored when the component is replaced.

NOTE: Some systems have magnetic surfaces. Ensure that the screws are not left attached to such surface when

replacing a component.

NOTE: Screw color may vary with the configuration ordered.
