– 8
The scope of delivery of your appliance is il-
lustrated on the packaging. Check the con-
tents of the appliance for completeness
when unpacking.
In the event of missing accessories or any
transport damage, please contact your
dealer.
These operating instructions describe the
basic models of the high pressure cleaners
shown on the front cover.
These operating instructions describe the
maximum equipment. Depending on the
model, there are differences in the scopes
of delivery (see packaging).
Illustrations on fold-out
pages!
1 Coupling element for
water connection
2 Water connection with integrated sieve
3 Appliance switch "0/OFF“/ „I/ON“
4 High pressure hose
5 Dosage regulator for detergent
6 Storage for trigger gun
7 High-pressure hose drum
8 Transport handle
9 Hand crank for hose drum
10 Storage of Plug 'n' Clean detergent bot-
tle with detergent connection
11 Storage for accessories
12 Option
Storage hook for mains connection ca-
ble
13 Option
Automatic coiling for mains cable
14 Mains cable with mains plug
15 Plug 'n' Clean detergent bottle with
locking lid
16 Wheels
17 Trigger gun
18 Lock trigger gun
19 Key to detach the high pressure hose
from the trigger gun
20 Washing brush
21 Spray lance with Dirtblaster
22 Spray lance with pressure regulation
(Vario Power)
Special accessories expand the possibili-
ties of using your appliance. Please contact
your KÄRCHER dealer for further informa-
tion.
Mount loose parts delivered with appliance
prior to start-up.
Illustration
Place the bottom holder into the recess-
es and push forward until it audibly
locks in.
Illustration
Insert the top holder and push down all
the way.
Option
Illustration
Install the top storage hook.
You will need the 2 included screws as well
as a Philips screwdriver PH 2.
Illustration
Insert both detergent hoses onto the
hose fittings.
Install the dosage regulator and con-
nect using 2 screws.
Illustration
Wind up the high-pressure hose on the
hose drum.
Illustration
Slide the free end of the coiled high
pressure hose through the recesses on
the dosage regulator.
Illustration
Attach the transport handle, insert the
bolts into the bores and screw them in.
Illustration
Press the connecting fitting from the
short high pressure hose into the brass
intake until it locks into place audibly.
Operation
Scope of delivery
Description of the Appliance
Special accessories
Before Startup
Install the storage for hand-spray gun
Install the storage hook for the mains
connection cable
Install the dosage regulator for
detergent
Install the transport handle
18 EN
