Accessories
Thank you for purchasing this LGE product
Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
OWNER'S MANUAL
/Cards
15-pin D-SUB Signal Cable
(To set it up, this signal cable may be
attached to this product before
shipping out.)
IMPORTANT
This accessories may look different from those shown here.
User must use shielded signal interface cables (D-SUB 15 pin cable) with ferrite cores to
maintain standard compliance for the product.
USB Extension Cable
Power Cord AC-DC adapter
(Depending on the country)
AC-DC adapter
(Depending on the country)
Or
