LG N224WHA-BS [24/28] Specifications
![LG N224WHA-BS [24/28] Specifications](/views2/1086507/page24/bg18.png)
22
Specifications
Display
Sync Input
Video Input
Resolution
Plug&Play
Power
Consumption
Dimensions
& Weight
Tilt Range
Power Input
AC-DC Adapter
Environmental
Conditions
Stand Base
Power cord
55.9 cm (21.9 inch) Flat Panel Active matrix-TFT LCD
, Anti-
Glare coating
Visible diagonal size: 55.9 cm
0.282 mm x 0.282 mm pixel pitch
Horizontal Freq. 30 kHz to 66 kHz (Automatic)
Vertical Freq. 57 Hz to 63 Hz (Automatic)
D-SUB Signal Input 15 pin D-SUB Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
LAN Signal Input LAN Connector
Input Form LAN Signal
Max VESA 1680 x 1050 @ 60 Hz
Recommend VESA 1680 x 1050 @ 60 Hz
DDC 2B (Only for D-SUB Input)
On Mode
: 29 W (Typ.)
Sleep Mode ≤ 5 W (LAN) / 1 W (D-SUB)
Off Mode ≤ 1 W
With Stand Without Stand
Width 51.57 cm ( 20.30 inch) 51.57 cm ( 20.30 inch)
Height 42.32 cm ( 16.66 inch)
(
Min
.)
34.46 cm ( 13.57 inch)
53.32 cm( 20.99 inch)
(
Max
.)
Depth 24.16 cm ( 9.51 inch) 5.91 cm ( 2.32 inch)
Net 5.3 kg (11.78 lb)
Tilt -6˚ to 17˚
19 V 3.0 A
Type PA-1650-68,manufactured by LITEON TECHNOLOGY CORP.
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Attached ( ), Detached ( O )
Wall-outlet type
NOTE
Information in this document is subject to change without notice.
