LG GH22LP20BlackRetail [12/14] Troubleshooting

Troubleshooting

Before Requesting Service

Before calling for service, check this list.

• The drive doesn’t have power.

• Is the power supply cable from the host computer plugged in?

• Is the Power Connector to the drive securely attached?

• The system doesn’t start.

• Are the Primary and Secondary connections and the Master and Slave settings

correct?

• Is the total length of the IDE cable 18 inches or less?

• Is each connector completely attached?

Other connections may have been knocked lose while installing the drive.

• Cannot Read or Write Discs.

• Is the condition of everything else in the system (CPU, hard disc, and others)

as it should be? (See system environment page 2.)

• Does the CD or DVD disc have dirt or scratches?

• Did a screen saver or other application operate while writing to the disc?

• Is there enough free space on the CD, DVD and DVD-RAM disc?

• Does writing fail even using the simulation test?

• Is the disc loaded in the drive with the read/write surface facing the right

direction? (label up)

• Is the drive installed in the correct orientation?

•Was the drive or disc moved from a low temperature environment to a high

temperature environment? (There is a possibility of condensation on the lens in

the drive or on the surface of the disc.)

• Using a 40-pin IDE cable might bring the '04/08/03 error (LOGICAL UNIT

COMMUNICATION CRC ERROR (ULTRA-DMA/32))'.

In this case, substitute to 80-pin type IDE cable is highly recommended.

This kind of error is hardly detected from some specific motherboard.

When you call for service, be prepared to give as much information as possible of

your system, environment, and the specific problem. (What happened? When?

How long? What was going on? Were there any error messages displayed? etc.)

Please Note: Since this product supports Region Playback Control Phase II,

a certain MPEG decoder card or Software without regional code setting may

cause this drive not to read DVD-ROM discs. This Drive enables you to change

the regional code up to 5 times.
