LG GP40NW10 [2/4] Location and function of controls

1. Disc Tray

2. Drive activity indicator

The LED is used to indicate the operation of

drive.

3. Eject Button

4. Emergency Eject Hole

1. USB Connector (mini)

This connector is used to connect to the USB

2.0 cable.

Location and function of controls

Removing the USB converter cable (For Windows)

The drive supports the plug and play(not swap) function of Windows, and can be removed and inserted by

performing the following operation.

1. Stop the application software being currently used.

2. Click the icon “ ” of the taskbar located on your screen’s bottom right side.

3. Click “Safely Remove USB Mass Storage Device-Drive[x:]”.

4. Click “Ok” and then remove the USB converter cable.

1 2

3 4

This following is the general figure of the design of the drive.

The drive’s appearance and specifications may change without prior notice.

Front

Rear

NOTE

Don’t remove the USB 2.0 cable when the busy indicator on the drive blinks, or during computer startup.

The removing procedure varies depending on your OS.
