LG BE06 [5/15] Introduction
![LG BE06 [5/15] Introduction](/views2/1086685/page5/bg5.png)
Thank you for purchasing the LG External Drive.
Features
• Universal Serial Bus (USB) 2.0 interface
• Buffer Under Run error protection technology
• Emergency eject support
• Bear media loading with power eject.
• CD-R/RW, DVD-R/RW/+R/RW/+/-R DL, DVD-RAM, BD-R/RE(SL/DL) read and write
compatible, CD Family, DVD-ROM, BD-ROM and HD DVD-ROM read compatible.
• Supports region playback control Phase II.
• Supports LightScribe Direct Label Printing Technology.
• To achieve maximum Record & Write speed your system may require data to be
copied first to the computer’s hard drive rather than directly from another source
disc or drive.
Introduction
2
System meeting the following requirements is needed in order to use USB 2.0
operation with this drive.
• Computer that is equipped with a USB 2.0 – compliant USB connector or PCI
adapter card, and on which the USB 2.0 EHCI (Enhanced Host Controller
Interface) driver software
1)
has been installed.
1)
The USB 2.0 EHCI driver software is supplied with currently available PCI
adapter cards that conform to USB 2.0. Further, Microsoft has released the USB
2.0 EHCI driver software for Windows XP, therefore it is also possible to use this
driver software with Windows XP.
If you want to know in detail, please contact your USB 2.0 adapter dealer or consult
your PC manufacturer, or consult the Microsoft Corporation Web site.
• Please note: Certain software (i.e. particularly those including Video playback) may
require a considerably increased specification PC to give acceptable results. While
this Blu-ray Disc Rewriter & HD DVD-ROM Drive can read DVD-video or
BD-MV(BD-ROM) discs, decoding them to display on your pc’s monitor requires
separate MPEG, H.264 or VC-1 decoding that is done by separate hardware (either
an MPEG, H.264 or VC-1 decoder card or MPEG, H.264 or VC-1 decoding done
by your video card), or separate software that you install to do MPEG, H.264 or
VC-1 decoding. For further details, refer to the documentation that comes with
MPEG, H.264 or VC-1 software.
Cautions
Содержание
- Fcc compliance statement 2
- The appliance is not intended for use by young children or infirm persons without supervision 3
- Appendix 4
- Contents 4
- Installation 4
- Introduction 4
- Operation 4
- Package contents 4
- Cautions 5
- Features 5
- Introduction 5
- Operating environment 6
- System requirements 6
- This unit can be operated in the system environment explained here 6
- Ac adapter 7
- Follow these precautions when handling the drive or discs 7
- Important precautions 7
- Installation avoid placing the drive in a location subject to high humidity high temperature excessive dust mechanical vibration direct sunlight 7
- Operation 7
- Operation through a usb hub cannot be guaranteed 7
- Precautions 7
- Location and function of controls 8
- Connecting to computer notes 9
- Hardware installation 9
- Installation 9
- Removing the usb converter cable 10
- Ejecting a disc 11
- Emergency eject 11
- Loading a disc 11
- Loading and ejecting a disc 11
- Operation 11
- Listening to sound 12
- Playing a music cd 12
- Playing dvd video and mpeg2 movie video 12
- Appendix 13
- If you are experiencing problems with the drive verify the following items since the problem may be caused by a device other than the drive check other things such as system settings or other software being used etc if you cannot resolve the problem after verifying these items contact your dealer or our customer service department 13
- Possible cause possible solution 13
- Problem 13
- Troubleshooting 13
- 3 strok 14
- Bd hd dvd dvd cd 14
- Specifications 14
- Wcight interface 14
- X 50 x 260 mm 14
- Always check your discs before inserting them into the drive 1 take care not to use worn cracked damaged warped or poor quality discs as this may cause damage to your drive 2 check the clear plastic on the center of the disc cracks here are the main cause of disc crush 3 do not play discs which are a non standard i e non circular shape such as heart shaped discs or discs in the shape of a business card 15
- Caution 15
- Excessive vibration or a sudden jolt to the drive during operation may cause a malfunction avoid exposing the drive to sudden changes in temperature as it may cause condensation to collect inside the drive 15
- How can you keep your discs from becoming damaged 1 when not in use remove discs from the drive 2 keep discs in the packaging supplied with them and out of direct sunlight and away from heat sources 15
- Made by 15
- P no 3828hm1055 15
- Please visit www lgservice com and install the automatic firmware download program lg odd online f w update this program will automatically check for new firmware releases and download them it is also included on the software discs that accompany our drives 15
- The disc rotates at high speed in the drive unit use of worn damaged or non standard discs can adversely affect the drive and cause the disc to shatter or crush while in use disc crush can only occur when you use a damaged disc in the drive it is an extremely rare occurrence but there are steps which can be taken to prevent it 15
