Installation

Hardware Installation

• Make sure you have a personal

computer with an open USB port or

eSATA port before connecting the drive

to your computer.

• Power for all device should be turn off

before attaching the cables.

Connect the drive to the computer as

shown in figure.

Connect the USB converter cable

(or eSATA cable) to the External Drive.

2. Connect the other end of the USB

converter cable (or eSATA cable) to

your computer.

3. Connect the AC adapter plug to the

power connector at the rear of the

drive.

Attach the AC adapter to the AC wall

outlet.

Make sure the power switch is turned on.

When the computer is ready, confirm

that the drive is detected. And then,

insert the supplied software CD into

the External Drive and install the

software.

• Please do not connect the AC adapter and USB 2.0 converter cable by any means

other than specified above.

• For optimal performance, using the ‘USB Booster Program’ in the Software CD is

recommended when you connect the USB cable.

• For optimal performance, using the SATA to eSATA Bracket is recommended when

you connect your old Desktop PC.

Connecting to computer

NOTES

To AC wall

outlet.

USB 2.0 Converter

cable

eSATA

cable
