7
TROUBLESHOOTING
Carefully re-read the instructions to make sure the unit is being operated properly.
Check the following before you take your unit to the local dealer for repair.
SYMPTOM CAUSE
There is no sound from the speakers. - The Volume control is set too low.
The radio does not work The FUNCTION switch is in the TAPE position
There is excessive static during FM reception. The antenna is not properly positioned
A cassette cannot be inserted into the compartment. The tape is inserted in the wrong direction.
The PLAY button does not lock in position after inserting cassette
tape
The tape is at its end and auto-stop function is in operation.
The RECORD button cannot be pressed down with a cassette tape
inside.
A tape with its safety tab removed has been inserted.
The TAPE does not play The PAUSE button is depressed.
The sound is weak or distorted during tape playback. The record/playback head is dirty.
A previous recording cannot be completely erased. The erase head is dirty.
If you find the unit is not working properly after checking the above chart, please take it to your nearest Services Center. Do not attempt to
repair it by yourself. Refer all servicing to qualified service personnel. If necessary, clean the unit with a piece of cloth dampened with water
only. Make sure the unit is disconnected from an AC power outlet.
SPECIFICATION
Power supply 230 V, 50 Hz
RMS 1.5 W
Net / Gross Weight 1.16 kg / 1.33 kg
Gift box dimension (L x W x H) 300 mm x 135 mm x 155 mm
Содержание
- H 1003 1
- Portable radio cassette recorder 1
- Description 2
- Important safeguards 2
- Ac operation 3
- Battery operation 3
- Function 3
- Function switch 3
- Power supply 3
- Sound adjustment 3
- Volume 3
- Antenna 4
- Cassette recorder operation 4
- Controls 4
- Operation 4
- Radio operation 4
- Cassette playback 5
- Recording 5
- Recording from radio 5
- Recording with built in microphone 5
- Automatic stop 6
- Erase protection 6
- Maintenence and care 6
- Special features 6
- Specification 7
- Troubleshooting 7
