Scarlett SC-SF111B21 [12/12] Do not attempt to repair adjust or replace parts in the appliance

IM022

www.scarlett.ru SC-SF111B21

 Ensure that the fan is switched off from the supply mains before

removing the guard.

 Do not attempt to repair, adjust or replace parts in the appliance.

Repair the malfunctioning appliance in the nearest service

center.

 If the product has been exposed to temperatures below 0ºC for

some time it should be kept at room temperature for at least 2

hours before turning it on.

 The manufacturer reserves the right to introduce minor changes

into the product design without prior notice, unless such changes

influence significantly the product safety, performance, and

functions.

 Manufacturing date is indicated on the unit and/or on packing as

well as in accompanying documents in the following format

XX.XXXX where first two figures XX is the month of production,

and following four figures XXXX is the year of production.

ASSEMBLING INSTRUCTIONS:

 The device is intended for air circulation in the room.

 Fan is packed disassembled. Before assembling make sure that all the required parts are

undamaged and included into the set.

 Do not plug in the device before its assembling is finished.

 Tighten stand tube to stand base with screw. Fix base cover to stand base with a screw

(supplied with a set).

 Unscrew out-joint, put the stand cover and base cover on the stand base, pull the extension

pole out then tighten the out-joint again.

 Place control box firmly on top of extension pole, tighten screw B.

 Unscrew the blade cap by turning clockwise and rear mesh nut by turning counter clockwise

and put both blade cap and rear mesh nut off the motor shaft.

 Put rear mesh on motor shaft.

 Secure it with rear mesh nut.

 Slide blades on motor shaft so that claws on motor shaft match the blades slots.

 Screw blade cap on shaft by turning counter clockwise.

 Put front mesh on rear mesh and close clips or screw mesh ring to secure meshs together.

 Adjust the fan vertically by vertical adjustment screw.

 The fan is ready for work.

OPERATION MANUAL

 CAUTION: To avoid electroconvulsive shock or fire danger, do not operate fan under the

conditions of increased humidity.

 Place fan only onto dry flat unyielding surface.

“1” For minimum operational speed;

“2” For medium operational speed;

“3” For maximum operational speed;

“0” The fan is switched off;

 On the upper part of the motor cover there is oscillating knob. If pressed, it makes the fan

cabinet with blades traverse from side to side. To cancel oscillating mode push oscillating knob

upward.

 To switch the fan off push the button “0”

MAINTENANCE

 Before cleaning unplug fan first.

 Clean front and rear meshs, blades, stand tube and stand base with soft moistened cloth and

wipe dry.

 Do not use abrasive cleansers

STORAGE

 Keep the device in normal conditions in dry place.

The symbol on the unit, packing materials and/or documentations means used electrical

and electronic units should not be toss in the garbage with ordinary household garbage. These

units should be pass to special receiving point.

For additional information about actual system of the garbage collection address to the local

authority.

Valid utilization will help to save valuable resources and avoid negative work on the public health

and environment which happens with incorrect using garbage.
